  • Page 1 MODEL G9298/G9299/G9300 HORIZONTAL/VERTICAL ROTARY TABLE OWNER'S MANuAL Copyright © MArCh, 2009 By grizzly industriAl, inC. WARNING: NO pORTION Of THIS MANuAL MAY BE REpRODuCED IN ANY SHApE OR fORM WITHOuT THE WRITTEN AppROVAL Of GRIZZLY INDuSTRIAL, INC. #ddts11512 printed in ChinA...
  • Page 2 This manual provides critical safety instructions on the proper setup, operation, maintenance and service of this machine/equipment. Failure to read, understand and follow the instructions given in this manual may result in serious personal injury, including amputation, electrocution or death. The owner of this machine/equipment is solely responsible for its safe use.

  • Page 3: Table Of Contents

    Table of Contents INTRODuCTION ..........................2 Manual Accuracy ........................2 Contact info ..........................2 Functional overview ........................2 identification ..........................3 specifications ..........................3 SECTION 1: SAfETY ........................4 safety instructions for Machinery ....................4 SECTION 2: SETup ......................... 6 needed for setup ........................

  • Page 4: Introduction

    If you have never used this type of machine or equipment before, WE STRONGLY RECOMMEND that you read books, review industry trade magazines, or get formal training before beginning any projects. Regardless of the content in this section, Grizzly Industrial will not be held liable for accidents caused by lack of training.

  • Page 5: Identification

    (horizontal) 3.944" 4.330" 4.750" height to Center hole (Vertical) 5.985" 6.750" 8.250" Morse taper Mt#3 Mt#3 Mt#4 t-slot number t-slot Width 0.465" 0.465" 0.545" diameter 8" 10" 12" shipping Weight 75 lbs. 117 lbs. 168 lbs. g9298/g9299/g9300 rotary table...

  • Page 6: Section 1: Safety

    TIRED OR UNDER THE INFLUENCE OF RESPIRATOR WHEN OPERATING DRUGS OR ALCOHOL. Be mentally alert MACHINERY THAT PRODUCES DUST. at all times when running machinery. Most types of dust (wood, metal, etc.) can cause severe respiratory illnesses. g9298/g9299/g9300 rotary table...
  • Page 7 16. MAKE SURE GUARDS ARE IN PLACE that type of dust. AND WORK CORRECTLY BEFORE USING MACHINERY. g9298/g9299/g9300 rotary table...

  • Page 8: Section 2: Setup

    Otherwise, filing a freight claim can be difficult. When you are completely satisfied with the condi- tion of your shipment, inventory the contents. g9298/g9299/g9300 rotary table...

  • Page 9: Inventory

    SuffOCATION HAZARD! Immediately discard all plas- tic bags and packing materi- als to eliminate choking/suf- focation hazards for children figure 3. Cleaner/degreasers available from and animals. grizzly. g9298/g9299/g9300 rotary table...

  • Page 10: Installation

    After installation, carefully check for any possible obstruc- tions that may interfere with the rotary table or its handwheel. g9298/g9299/g9300 rotary table...

  • Page 11: Spindle Alignment

    800–1000 rpM, then slowly move the mill table along the X-axis in one direction. Note: Refer to Accessories on Page 15 for test indicator options from Grizzly. When you find the edge of the rotary table spindle bore, note the position of the table on the handwheel dial.
  • Page 12 — if a deviation is found, loosen the rotary table mounting hex nuts, tap the rotary table into the proper position, then re-tight- en the mounting hex nuts. repeat Step 3 until the entire rotary table face is properly aligned with the mill spindle. -10- g9298/g9299/g9300 rotary table...

  • Page 13: Section 3: Operations

    D. Table Lock: When fully tightened, keeps the Regardless of the content in this section, table from rotating to reduce the strain on the Grizzly Industrial will not be held liable for gears during operation. When cutting circular accidents caused by lack of training.

  • Page 14: Adjusting Handwheel Scales

    Note: When changing directions with the the side of the table (see figure 8). handwheel, take into account any backlash. table handwheel scale scale At zero Vernier scale figure 8. table scale at zero degrees. -12- g9298/g9299/g9300 rotary table...

  • Page 15: Basic Operation

    Tip: When using the rotary table to machine several locations or with a complicated pattern, make a drawing with measurement details to help visualize the operation. This will reduce the risk of making errors during the operation. -13- g9298/g9299/g9300 rotary table...
  • Page 16 Move the mill table 2.25" to the right along its X-axis to align the cutter with the end of the Radius second circular slot. 10. repeat Steps 3–7 to complete the second Start circular slot. Here 0.25" figure 11. two 90° circular slots. -14- g9298/g9299/g9300 rotary table...

  • Page 17: Section 4: Accessories

    " shank. 0.030" range/0.0005" resolution these test indicators have an easy to read dial and a pivoting stylus that moves at right angles to the dial face. figure 15. g9629 universal indicator holder. figure 13. test indicator. -15- g9298/g9299/g9300 rotary table...
  • Page 18 When used with your rotary table and mill, these adjustable tailstocks provide the support you need for those longer workpieces. Clamps to your mill table with standard clamping hardware and allows precise and accurate adjustments. figure 19. h8370 power Feed. figure 17. Adjustable tailstock. -16- g9298/g9299/g9300 rotary table...

  • Page 19: Section 5: Maintenance

    80 hours of use, completely disassembly the rotary table, then thoroughly clean each part and re-lubricate. -17- g9298/g9299/g9300 rotary table...

  • Page 20: Surface Care

    -18- g9298/g9299/g9300 rotary table...
  • Page 21 Would you recommend Grizzly Industrial to a friend? _____ Yes _____No Would you allow us to use your name as a reference for Grizzly customers in your area? Note: We never use names more than 3 times. _____ Yes _____No 10.
  • Page 22 FOLD ALONG DOTTED LINE Place Stamp Here GRIZZLY INDUSTRIAL, INC. P.O. BOX 2069 BELLINGHAM, WA 98227-2069 FOLD ALONG DOTTED LINE Send a Grizzly Catalog to a friend: Name_______________________________ Street_______________________________ City______________State______Zip______ TAPE ALONG EDGES--PLEASE DO NOT STAPLE...

  • Page 23: Warranty And Returns

    WARRANTY AND RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance.
  • Page 24 Buy Direct and Save with Grizzly – Trusted, Proven and a Great Value! ® ~Since 1983~ Visit Our Website Today For Current Information On Events And Specials! • SECURE ORDERING • ORDERS SHIPPED WITHIN 24 HOURS -OR- FREE Call Today For A...
