Summary of Contents for InWin B1

  • Page 1 User Manual...
  • Page 2 Product Story The B1’ s extremely small footprint is perfect for small form factor builds such as HTPCs, light gaming PCs or even a LAN rig. The integrated ventilation in the exquisite streamline design provides a better thermal solution, and you...
  • Page 3: Specifications

    141 x 336 x 287 mm Package Dimensions 5.6" x 13.2" x 11.3" (H x W x D) 1.9 KG/ 4.2 lb Net Weight Gross Weight 2.2 KG/ 4.9 lb InWin products comply with RoHS regulations. ■ Specifications may vary based on different regions. ■...
  • Page 4 52 x 40 x 170 mm (L x W x H) 2.05" x 1.6" x 6.7" Warranty 3 Years Connectors Motherboard 24-pin CPU 4+4-pin PCIE 6+2-pin Peripherals SATA Floppy Power InWin products comply with RoHS regulations. ■ Specifications may vary based on different regions. ■...
  • Page 5 Speed Mode 24.09 CFM Air Flow 1.08mm/ H2O Air Pressure 4-Pin Connector 23.55dB(A) Noise Level Long Lifespan Sleeve Bearing Bearing Type >30,000 hrs. Life Expectancy InWin products comply with RoHS regulations. ■ Specifications may vary based on different regions. ■...
  • Page 6: Package Contents

    Package Contents 1.B1 Chassis 2.InWin 200W 80 PLUS Gold PSU 3.InWin 80mm Side fan x 1 4.QR Code Card 5.Accessories Bag...
  • Page 7: Accessories Bag

    Accessories Bag Hexagon Head Screws X 8 2.5” HDD Screws X 10 Cable Ties X 5 Foot-Stand Stickers X 4...
  • Page 8 Case Structure Tempered Glass Logo Power Button HDD/Power LED indicator USB 3.0 Ports HD Audio Port (CTIA ‒ SPK/Mic) Removable Foot-stand Release Panel...
  • Page 9 Case Structure 2.5” Drive Bay InWin 80mm Side Fan Motherboard Mounting Area InWin 200W 80 PLUS Gold PSU Fan Dust Filter...
  • Page 10: Motherboard Installation

    Installation Guide (Please follow the related chapters to assemble) Opening the Chassis Please release the two screws and lift up the top cover. Motherboard Installation Parts Required: Hexagon Head Screws.
  • Page 11 I/O Wires Installation Switch/LED Connector Black(P_LED) 1 2 Black (HDD) Black(P_LED) 3 4 Black (HDD) Black(P_SW) 5 6 NC Black(P_SW) 7 8 NC Key 9 10 NC...
  • Page 12 2.5” Drive Bays Installation Parts Required: 2.5” HDD Screws i.Release the two screws and remove the bottom cover. ii.Install the 2.5’ ’ HDD screws on your SSD screw holes. iii.Attach the SDD in the designated area and push towards the SATA direction.
  • Page 13 2.5” Drive Bays Installation How to Uninstall the 2.5” Drive Bays i.Push the panel ii.Pull towards the direction to release it.
  • Page 14 Foot-Stand Stickers Installation (Optional) Note: After installed, the stickers will be hard to remove. Please use wisely, we suggest using the chassis on vertical position for a better look. Parts Required: Foot-stand Stickers i.Release the two screws and remove the bottom cover. ii.Release the screws of the foot-stand and detach the foot-stand.
  • Page 15 Completing Installation Parts Required: Cable Ties *For more installation instructions, please scan the QR Code or watch the video in the website link https://youtu.be/cHm2nA2liQY...
  • Page 16 Please only use your fan in the computer case.. ■ Warranty * For more detailed warranty information, please visit the InWin retail website at www.in-win.com. * The actual product is subject to change without prior notice. InWin Development Inc. reserves the right to make final modifications.
  • Page 17 Copyright © 2020 InWin Development Inc. All Rights Reserved.
