- Page 1 INSTALLATION INSTRUCTIONS ProLine PL70 HEAVY FRAMELESS BYPASS BATH ENCLOSURE Copyright © Alumax Bath Enclosures 2013. All rights reserved. G03980848 5-1-13...
- Page 2 INSTALLATION WARNINGS Alumax Bath Enclosures by Sapa are intended to be installed by an experienced installer. If you need assistance with locating an experienced installer, contact us at 1.800.643.1514 or go to our website www.alumaxshowerdoor.com...
- Page 3 Page 4 of 9...
- Page 4 Notes: This is a two person installation. All marks made on tile, marble or fiberglass should be made lightly in pencil so they can be removed after the installation is complete. An optional method is to use masking tape on the walls and sill that can be removed as the installation progresses.
- Page 5 Glass Clips and Threshold – Mark the center point of the sill, along the centerline, established in step one. Make a mark 1/2” over toward the Fixed Panel [E] side and 11/16” outside of the centerline. Make another mark 2” over from the wall and 11/16”...
- Page 6 Door Panel – Notice that the Roller [O] has an offset attachment plate. Install the Rollers to the Door Glass [P] with the Plastic Washer [Q]against the Roller and the Roller Bushing [R] against the Roller Cap [S]. Adjust the roller so that the hole in the attachment plate is to the left or right.
- Page 7 Fixed Panel Installation - Install the “peel-and-stick” Wall Seal [EE] on the wall side edge of the Fixed Panel. Orient it with the open end to the inside of the enclosure. Lift the Fixed Panel and set it in the Glass Clips with the edge as tight to the wall as possible.
- Page 8 Finishing Up – Make sure that all fasteners are tight. Clean all exposed marks you made on the sill and walls of the shower stall. Clean the glass panels. Allow 24 hours for any silicone to completely cure, before using your new Alumax Shower Door. Page 9 of 9...
