Installation Instructions &
ELECTRIC HEATER WITH REMOTE CONTROL
READ AND SAVE THESE INSTRUCTIONS
READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR
MAINTAIN THE PRODUCT DESCRIBED.
PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION.
FAILURE TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL INJURY
AND/OR PROPERTY DAMAGE.
WARNING! To reduce the risk of fire, electric shock, or personal
injury, read all the instructions before using this heater.
Homeowner's
Operating Manual
Model: EF43D, EF44D, EF45D
Advertisement
Table of Contents
Related Manuals for Dynasty Fireplaces EF43D
Summary of Contents for Dynasty Fireplaces EF43D
- Page 1 Homeowner’s Installation Instructions & Operating Manual ELECTRIC HEATER WITH REMOTE CONTROL Model: EF43D, EF44D, EF45D READ AND SAVE THESE INSTRUCTIONS READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR MAINTAIN THE PRODUCT DESCRIBED. PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION.
-
Page 2: Important Instructions
IMPORTANT INSTRUCTIONS When using electrical appliances basic precautions should always be followed to reduce the risk of fire， electrical shock and injury to persons including the following： CAUTION- High temperature, keep electrical cords, drapery, and other furnishings at least 3 feet (0.9m) from the front of the heater and away from the side and rear. -
Page 3: Installation Instruction
Depth Mantel Minimum Depth Width Height Model （ W ） （ H ） （ D ） （ RD ） （ OW ） （ OH ） 660-690 590-620 EF43D 710/28 625/24.6 220/8.7 205/8 /26-27 /23-24 760-790 590-620 EF44D 810/31.9 625/24.6 220/8.7... -
Page 4: Electrical Connection
WARNING! Keep drapery and other furnishings at least 3ft /0.9m from the front and sides of the electric fireplace. Installation: NOTE ！ • After installation, ensure that there is a space between the wall and the fireplace insert. Install insert: ！... -
Page 5: Temperature Limiting Control
OPERATING INSTRUCTION Power Make sure the Power Switch, located on the control panel, is in the OFF position. Plug the power cord into a 110~120 Volt 15 Amp outlet. Make sure the outlet is in good condition and that the plug is not loose. -
Page 6: Control Panel
Control Panel Located on the right and top side panel of the fireplace. NAME FUNCTION BUTTON Turn on the main power supply. A long “beep” sound will be heard when the switch is turned on On Position “I”. POWER SWITCH Note: The remote control will lost the memory for function settings when the switch is turned on Off Position “0”. -
Page 7: Remote Control
Remote Control Control panel Power Switch must be ON to use remote control. Aim the remote control at the remote receiver. Make sure you hear a beep NOTICE: each time you press the button! If not, the fireplace will not respond to the signal. - Page 8 Dynasty Fireplaces | Unit 10 - 3071 No. 5 Road, Richmond, BC V6X 2T4 Canada Tel: (604) 821-1009 | Toll free: 1-877-521-1009 | Fax: (604) 821-1019 Http: www.dynastyfireplace.com | Email: info@dynastyfireplace.com...
