INTRODUCTION
Dear Customer,
thank you for choosing one of our products. We hope that you will be completely satisfied with this machine
and that it fully meets your expectations. This manual has been compiled in order to provide you with all
the information you need to get acquainted with the machine and use it safely and efficiently. Don't forget
that it is an integral part of the machine, so keep it handy so that it can be consulted when necessary, and
pass it on to a further user if you resell or loan the machine.
Your new machine has been designed and manufactured in pursuance with current regulations, and is
safe and reliable if used in compliance with the instructions provided in this manual (proper use). Using the
machine in any other way, or non-compliance with the safety specifications relative to use, maintenance
and repair is considered "improper use" which will invalidate the warranty, relieve the manufacturer from
all liabilities, and the user will consequently be liable for all and any damage or injury to himself or others.
Since we regular improve our products, you may find slight differences between your machine and the de-
scriptions contained in this manual. Modifications can be made to the machine without notice and without
the obligation to update the manual, although the essential safety and function characteristics will remain
unaltered. In case of any doubts, please contact your dealer. And now enjoy your work!
TABLE OF CONTENTS
1. Identification of the main components ........................................ 2
2. Symbols ..................................................................................... 3
3. Safety requirements ................................................................... 4
4. Machine assembly ..................................................................... 6
5. Preparing to work ....................................................................... 7
6. How to start - Use - Stop the engine .......................................... 8
7. Using the machine ................................................................... 10
8. Maintenance and storage ......................................................... 12
9. Troubleshooting ....................................................................... 14
10. Technical data ......................................................................... 14
11. Accessories ............................................................................. 16
1
EN
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for GGP ITALY B 28
Summary of Contents for GGP ITALY B 28
-
Page 1: Table Of Contents
INTRODUCTION Dear Customer, thank you for choosing one of our products. We hope that you will be completely satisfied with this machine and that it fully meets your expectations. This manual has been compiled in order to provide you with all the information you need to get acquainted with the machine and use it safely and efficiently. Don’t forget that it is an integral part of the machine, so keep it handy so that it can be consulted when necessary, and pass it on to a further user if you resell or loan the machine. Your new machine has been designed and manufactured in pursuance with current regulations, and is safe and reliable if used in compliance with the instructions provided in this manual (proper use). Using the machine in any other way, or non-compliance with the safety specifications relative to use, maintenance and repair is considered “improper use” which will invalidate the warranty, relieve the manufacturer from all liabilities, and the user will consequently be liable for all and any damage or injury to himself or others. Since we regular improve our products, you may find slight differences between your machine and the de- scriptions contained in this manual. Modifications can be made to the machine without notice and without the obligation to update the manual, although the essential safety and function characteristics will remain unaltered. In case of any doubts, please contact your dealer. And now enjoy your work! TABLE OF CONTENTS 1. Identification of the main components ........2 2. Symbols ..................3 3. Safety requirements ..............4 4. Machine assembly ..............6 5. Preparing to work ............... 7 6. ... -
Page 2: Identification Of The Main Components
IDENTIFICATION OF MAIN COMPONENTS 1. IDENTIFICATION OF MAIN COMPONENTS MAIN COMPONENTS 1. Power unit 2. D rive tube 3. C utting device a. Blade with 3 or 4 points b. Cutting line head 4. C utting device guard 5. Front handgrip 6. Guard 7. Handlebar ... -
Page 3: Symbols
SYMBOLS 2. SYMBOLS 1) Warning! Danger. The failure to use this ma- 6) Maximum cutting device speed. Only use sui- chi n e correctly can be hazardous for oneself and table cutting devices. others. 7) Do not use the circular saw blade. Danger: 2) Read the instruction manual before using the Using the circular saw blade with machines ma c hine. marked ... -
Page 4: Safety Requirements
SAFETY REQUIREMENTS 3. SAFETY REQUIREMENTS A) TRAINING – k eep the fuel in containers which have been spe- cifically manufactured and homologated for such 1) Read the instructions carefully. Become a c - use; quainted with the controls and the proper use of – n ever smoke when handling fuel; the machine. Learn how to stop the engine qui c kly. – s lowly open the fuel tank to allow the pressure 2) ... - Page 5 SAFETY REQUIREMENTS 2) Mow only in daylight or good artificial light. en c losure. 3) Take on a firm and well-balanced position: 4) To reduce fire hazards, keep the engine, ex h aust – w here possible, avoid working on wet, slippery silencer and fuel storage area free from saw d ust, ground or in any case on uneven or steep ground branches, leaves, or excessive grease; ne v er leave that does not guarantee stability for the operator; containers with the cut debris inside the storage – ...
-
Page 6: Machine Assembly
MACHINE ASSEMBLY 4. MACHINE ASSEMBLY • 3 or 4 point blade (Fig. 4) IMPORTANT The machine is supplied with some of the components disassembled and the fuel tank empty. WARNING! Wear protective gloves and fit the blade guard. WARNING! Always wear strong work – R emove the blade (if fitted) as described in gloves to handle the cutting devices. -
Page 7: Preparing To Work
MACHINE ASSEMBLY / PREPARING TO WORK When mounting, When mounting, – E nsure that the grooves in the inner ring-nut (8) – E nsure that the grooves in the inner ring-nut match up perfectly with the angle transmission (4) match up perfectly with the angle tranmis- (3). sion (3). – F it the blade (1) and outer ring-nut (7). – F it the cutting line head (1) screwing it up in an – R efit the washer (6) and the nut (5), fully tighte- anticlockwise direction. -
Page 8: How To Start - Use - Stop The Engine
PREPARING TO WORK / HOW TO START - USE - STOP THE ENGINE – Keep the petrol and fuel mixture in ho mo IMPORTANT Periodically clean the petrol log ated fuel containers, in safe place, away and fuel mixture containers to remove any even from any flames or heat sources. tual deposits. –... - Page 9 HOW TO START - USE - STOP THE ENGINE 3. P ress the primer device button (6) 3 or 4 ti m es USE OF THE ENGINE (Fig. 8) to prime the carburettor. 4. H old the machine firmly on the ground with one Cutting device speed is regulated by the throttle hand on the power unit, in order not to lose trigger (2), located on the rear handgrip (4) or the control of the machine during startup (Fig. 9). right handgrip (4a) of the handlebar. The throttle trigger only works if the lockout (3) is IMPORTANT To prevent distortions, the pressed at the same time.
-
Page 10: Using The Machine
USING THE MACHINE 7. USING THE MACHINE The belt (1) must go over the left shoulder towards To respect people and the environment: the right hip. – T ry not to cause any disturbance. – S crupulously comply with local regulations and provisions for the disposal of waste ma- • D ouble belt models terials after sawing. – S crupulously comply with local regulations The belt (2) must be worn with: and provisions for the disposal of oils, petrol, – t he machine’s support and snap-hook coupling on damaged parts or any elements which have a the right side (2.1);... - Page 11 USING THE MACHINE WORKING TECHNIQUES keeping the cutting device at a distance from the operator. a) 3-point blade (Fig. 11) Start cutting above the undergrowth and then move • C utting near fences/foundations (Fig. 14) down with the scything blade so as to cut the brush into small pieces. Slowly approach the cutting line head to fences, posts, rocks, walls, etc. without hitting them hard. b) 4-point blade (Fig. 12) If the line strikes a solid object it could break or be- come worn; if it gets tangled in a fence it could break Proceed using the machine as a traditionalscythe, abruptly.
-
Page 12: Maintenance And Storage
MAINTENANCE AND STORAGE 8. MAINTENANCE AND STORAGE Correct maintenance is essential to maintain the original efficiency and safety of the machine over CHECKING THE SPARK PLUG (Fig. 18) time. Periodically remove and clean the spark plug us- ing a metal brush to get rid of any deposits. WARNING! During maintenance ope ra tions: Check and reset the correct distance between the electrodes. – Remove the spark plug cap. – Wait until the engine is sufficiently cold. – Use protective gloves when handling the Replace the spark plug and fasten it firmly using ... - Page 13 MAINTENANCE AND STORAGE The references for correct sharpening are given LONG PERIODS OF DISUSE in Fig. 20: IMPORTANT A = Incorrect sharpening If you are not going to use the B = Sharpening limits machine for a period of more than 23 months, we C = Incorrect and unequal angles recommend you do a few things before putting it away.
-
Page 14: Troubleshooting
B 33 mod. ...... 2520-3080 rpm Weight B 44 mod. ...... 2520-3080 rpm B 28 ............ 6.8 kg Maximum engine rotation speed B 28 J ............ 7.3 kg B 28 mod. ........ 10000 rpm B 28 D ........... 6.9 kg B 33 mod. ........ 10000 rpm B 28 JD .......... 7.7 kg ... - Page 15 TECHNICAL SPECIFICATIONS Model Measured equivalent B 28 noise and vibration values B 28 D B 28 JD B 33 B 33 D B 44 B 44 D B 28 J Operator ear noise pressure level dB(A) Measured sound power level dB(A) 111,67 111,67 114,2 112,67 115,42 112,6 113,93 Measurement uncertainty dB(A) 2,63...
-
Page 16: Accessories
Code Model: B 28 B 33 B 44 118801127/0 118801418/0 118801126/0 (M10 x 1,25 sx F) Code Model B 28 J 118801754/0 Hedge trimmer 118801755/0 118801756/0 Pruner... - Page 17 (Directive Machines 2006/42/CE, Annexe II, partie (Machine Directive 2006/42/EC, Annex II, part A) (Maschinenrichtlinie 2006/42/EG, Anhang II, Teil La Società: GGP Italy S.p.A. – Via del Lavoro, 6 – 31033 Castelfranco Veneto (TV) – Italy 1. The Company 1. La Société...
- Page 18 © by GGP ITALY • Soggetto a modifiche senza preavviso • Подлежи на промени без предупреждение • Možnost změn bez předešlého upozornění • Ret til ændringer forbeholdes • Kann ohne Vorankündigung geändert werden • Υπόκειται σε αλλαγές χωρίς προειδοποίηση • Subject to modi- fications without notice • Sujeto a modificaciones sin previo aviso • Võimalikud muudatused ilma ette teatamata • Voidaan tehdä muutoksia ilman ennakkoilmoitusta • Sujet à des modifications sans aucun préavis • Podložno promjenama bez prethodne obavijesti • Előzetes értesítés nélkül módosítható • Objekto pakeitimai be perspėjimo • Var tikt mainīts bez iepriekšēja brīdinājuma • Подлежи на промени без претходно известување • Kan zonder kennisgeving wijzigingen ondergaan • Kan endres uten forvarsel • Poddawany modyfikacjom bez awizowa- nia • Sujeito a alterações sem aviso prévio • Poate fi modificat, fără preaviz • Moжет быть изменено без преомления • Lahko pride do sprememb brez predhodnega obvestila • Kan utsättas för modifieringar utan att detta meddelas • Önceden haber verilmeksizin değiştirilebilir...
