Handling Run-Time Errors With The Error Task - Nidec SM-Applications Series User Manual

Table 11-2 SM-Applications Modules & Motion Processors Error Codes
Error
Code
74
75
76
77
78
79
80
81
82
11.4

Handling Run-Time Errors with the ERROR task

Certain run-time errors will cause the DPL ERROR task to be invoked if it exists. This
provides a convenient way to safely handle the error condition and take whatever action
is necessary, such as a controlled stop of the system or signalling of an alarm.
When an ERROR task runs, all other DPL tasks will have been stopped. Therefore the
ERROR task has exclusive execution rights. Once the ERROR task has completed, the
DPL program ends and no other DPL tasks operate (though it is possible to reset and
restart the program - more details on this below).
Drive trips do not cause the ERROR task to run. Only certain DPL program errors do.
NOTE
Within the ERROR task all standard DPL commands may be used as well as most
function blocks. All Unidrive SP and Second Processor parameters can be accessed.
The run-error code can be determined using this parameter:
Pr 88.01
Access
Default
This parameter has two purposes - when read it will return the run-time error code the
same as Pr 81.50 (note - it will not return drive trip codes). The parameter is cleared to
zero on reset and when the user program execution is started.
SM-Applications Modules & Motion Processors User Guide
Issue Number: 4
Reason
Over-temperature
Hardware unavailable. The user program attempted to
access unavailable hardware. e.g. if access is made to
digital I/O, RS485 port or CTNet on SM-Applications Lite
module.
Module type cannot be resolved. Module is not
recognised.
Inter-Option module comms error with module in slot 1.
Inter-Option module comms error with module in slot 2.
Inter-Option module comms error with module in slot 3.
Inter-Option module comms error with module unknown
slot.
• Slot selected as the reference or feedback does not
contain a position option module
• Attempt to change the Reference source or the
Feedback source in more than one task.
APC internal error. See Pr 81.38 . This may be caused by
one of the following:
• CAM table too small
• A change of too many CAM segments has occurred
at the CAM table input
• CAM is selected but size is zero
• CAM absolute mode selected and Reset Index or
Reset Position in segment is out of range
Communcations to drive faulty.
Error Status / Reset
RW Range
N/A Update Rate On error
Trip
Drive?
Yes
Yes
Yes
Yes
Yes
Yes
Yes
May
May
0 to 9999
ERROR Prog
task? Halted?
Yes Yes
Yes Yes
No Not Run
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
115
