alex CRIB
t h a n k y o u f o r s e l e c t i n g a d u c d u c p r o d u c t
Please check contents against the components list in
these instructions. Also, please ensure there was no
damage that may have occurred in shipping.
If any components are missing or you find any dam-
age, please contact ducduc before continuing.
Read all the instructions before use of the CRIB.
Please remember to securely tighten all bolts
and fasteners, and periodically check to make sure
every component is properly and securely in place
and all bolts and fasteners are tight.
Pay close attention to the safety warnings in
these instructions and on CRIB labels.
A minimum of two people is required to safely
assemble and move the CRIB. Do not attempt to
move this CRIB alone - dragging or sliding it across a
floor may cause structural damage.
CAUTION: Any mattress
used in this CRIB must
be at least 27
by 51
inches with a
5 / 8
thickness not exceeding
6 inches.
K E E P I N S T R U C T I O N S F O R F U T U R E U S E
inches
1 / 4
8/10/2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the alex CRIB and is the answer not in the manual?

Questions and answers

Related Manuals for ducduc alex CRIB

Summary of Contents for ducduc alex CRIB

  • Page 1 Also, please ensure there was no damage that may have occurred in shipping. If any components are missing or you find any dam- age, please contact ducduc before continuing. Read all the instructions before use of the CRIB. alex CRIB...
  • Page 2 components pictures are not drawn to scale END PANEL SIDE RAIL MATTRESS SUPPORT PANEL RAIL CONNECTOR BOLT MATTRESS SUPPORT BOLT MATTRESS SUPPORT PIN LOCKING WASHER - LARGE (5/16”) REGULAR WASHER - LARGE (5/16”) LOCKING WASHER - SMALL (4/16”) ALLEN WRENCH (4mm) REGULAR WASHER - SMALL (4/16”) SCREWDRIVER (not included)
  • Page 3 assembly Lay END PANEL on floor with rail-connector-holes facing up. rail-connector-holes rail-connector-holes Align SIDE RAIL to END PANEL so that the rail-connector-holes on SIDE RAIL line up with the rail-connector-holes on END PANEL Make sure the four mattress-support-holes face the bottom and inside of END PANEL .
  • Page 4 Attach one LOCKING WASHER and one REGULAR WASHER to each RAIL CONNECTOR BOLT and insert two RAIL CONNECTOR BOLTS in rail-connector-holes and tighten with ALLEN WRENCH Align second SIDE RAIL to END PANEL making sure that mattress-support-holes face the bottom and inside of CRIB. Refer to diagram for proper orientation.
  • Page 5 Carefully stand crib upright. This requires two people. One person holds onto crib to prevent it from tipping over during assembly step 6. Line up other END PANEL so its rail-connector-holes align with the rail-connector-holes on the SIDE RAILS Attach LOCKING WASHERS and REGULAR WASHERS to RAIL CONNECTOR BOLTS and insert and tighten...

  • Page 6: Side Rails

    The MATTRESS SUPPORT PANEL may be installed in one of four positions. See the four different mattress-support-holes in each corner of the CRIB. First, select the desired mattress height. Then, unscrew the MATTRESS SUPPORT from each MATTRESS SUPPORT BOLT . . Insert the smooth ends of each MATTRESS SUPPORT PIN in the desired mattress-support-holes on SIDE RAILS...

  • Page 7: Support Panel

    Attach one REGULAR WASHER and one LOCKING WASHER on top of each MATTRESS SUPPORT PIN Secure and tighten each of the four MATTRESS SUPPORT BOLTS to each of the four MATTRESS SUPPORT PINS Use SCREWDRIVER to tighten securely. Press firmly in center of MATTRESS SUPPORT PANEL to ensure proper placement.

  • Page 8: Operation

    operation The mattress height should be lowered as your baby grows to ensure that he/she does not climb out of the CRIB. When child is able to pull to standing position, set mattress to lowest position and remove bumper pads, large toys and other objects that could serve as steps for climbing out.

  • Page 9: Decal Application

    decal application decal application for optional decal Please follow these directions to apply optional vinyl decal. Make sure that the crib surface is clean and dry. Vinyl is easier to apply before the crib is assembled. Use invisible tape to attach Gently lift the decal up without slowly peel off the back layer decal at the desired location.
  • Page 10 Securely tighten loose bolts and other fasteners. DO NOT use crib if any parts are missing, damaged or broken. Contact ducduc for replacement parts and instructional literature if needed. DO NOT substitute parts.
