OSLO CRIB
Thank you for selecting a ducduc for nod product.
Please check contents against the components list in these
instructions. Also, please ensure there was no damage that
may have occurred in shipping. If any components are
missing or you find any damage, please contact The Land
of Nod at 800-933-9904 before continuing.
Read all the instructions before use of the CRIB.
Please remember to securely tighten all bolts and fasteners
and periodically check to make sure every component is
properly and securely in place.
Pay close attention to the safety warnings in these
instructions and on CRIB labels.
A minimum of two people is required to safely assemble
and move the CRIB. Do not attempt to move this CRIB
alone - dragging or sliding it across the floor may cause
structural damage.
CAUTION:
used in this CRIB must be at
least 27
1/4
inches with a thickness not
exceeding 6 inches.
Keep instructions for future use.
Any mattress
inches by 51
5/8
Advertisement
Related Manuals for ducduc OSLO
Summary of Contents for ducduc OSLO
- Page 1 Thank you for selecting a ducduc for nod product. Please check contents against the components list in these instructions. Also, please ensure there was no damage that may have occurred in shipping. If any components are missing or you find any damage, please contact The Land of Nod at 800-933-9904 before continuing.
- Page 2 pictures are not drawn to scale MATTRESS SUPPORT PANEL SIDE RAIL END RAIL BASE TOP FRAME RAIL TOP FRAME ASSEMBLY removable support RAIL CONNECTOR BOLT (40MM) X 12 MATTRESS SUPPORT BOLT CONNECTOR BOLT (45MM) X 14 MATTRESS SUPPORT PIN BASE CONNECTOR BOLT (50MM) X 10 LOCKING WASHER (5/16”) ALLEN WRENCH...
- Page 3 assembly Lay SIDE RAIL on floor with rail connector holes facing up. rail connector holes rail connector holes Align END RAIL to SIDE RAIL so that the rail connector holes on END RAIL line up with the rail connector holes on SIDE RAIL .
- Page 4 tipping over during assembly step 6. One person holds onto crib to prevent it from tip tipping over during assembly step 6. tipping over during assembly step 6. tipping over during assembly step 6. tipping over during assembly step 6. assembly step 6.
- Page 5 Carefully stand crib upright. This requires two people. One person holds onto crib to prevent it from Carefully stand crib upright. This requires two people. One person holds onto crib to prevent it from Carefully stand crib upright. This requires two people. Carefully stand crib upright.
- Page 6 Remove support bracket from TOP FRAME ASSEMBLY Place TOP FRAME ASSEMBLY on top of crib rails and secure in place with ten CONNECTOR BOLTS , LOCKING WASHERS , and REGULAR WASHERS shown below. Place TOP FRAME RAIL on top of crib rails and secure in place with four CONNECTOR BOLTS , LOCKING WASHERS , and REGULAR WASHERS...
- Page 7 Attach X-FOOT to X-FOOT using notches to form X-frame. Place BASE on top of X-frame. Attach each foot to corner bracket of base using RAIL CONNECTOR BOLTS LOCKING WASHERS , and REGULAR WASHERS , and tighten with ALLEN WRENCH Flip crib rails over so top is on floor on a blanket or carpet. Place BASE on crib rails and secure in place with ten BASE CONNECTOR BOLTS , LOCKING WASHERS...
- Page 8 over during Tighten all RAIL CONNECTOR BOLTS on SIDE RAILS and END RAILS with ALLEN WRENCH The MATTRESS SUPPORT PANEL may be installed in one of four positions. See the four different mattress support holes in each corner of the CRIB. First, select the desired mattress height.
- Page 9 Attach one LOCKING WASHER and one REGULAR WASHER on top of each MATTRESS SUPPORT PIN . Secure and tighten each of the four MATTRESS SUPPORT BOLTS to each of the four MATTRESS SUPPORT PINS Use SCREWDRIVER to tighten securely. Press firmly in center of MATTRESS SUPPORT PANEL to ensure proper placement.
- Page 10 operation The mattress height should be lowered as your baby grows to ensure that he/she does not climb out of the CRIB. When child is able to pull to standing position, set mattress to lowest position and remove bumper pads, large toys and other objects that could serve as steps for climbing out.
- Page 11 Securely tighten loose bolts and other fasteners. DO NOT use crib if any parts are missing, damaged or broken. Contact ducduc for replacement parts and instructional literature if needed. DO NOT substitute parts.
