X250 WiFi Camera Installation
Kit Contains:-
Phone holder
Phone holder bracket
Thumb screws and nuts
FPV camera
Longer standoff feet
Installing the Phone Holder
1. Place the rear half of the phone holder bracket onto the back of
the transmitter, the location lugs will line up with the holes on
the transmitter
2. Place the front half of the phone holder bracket on the front of
the transmitter in-line with the rear holder and screw in place
with the two thumb screws and nuts provided.
3. Attach the Phone holder to the Phone holder bracket by connecting the two halves together.
Page 1 of 3
