Summary of Contents for Citizen A010

  • Page 2 Please request for The Citizen Customer Card (a warranty card) (see page 60). * You need to register in order to obtain manufacturer's warranty service. * The Citizen is sold only in Japan and therefore the warranty service for this product is not available overseas. <Protective Stickers>...
  • Page 3 Safety precautions This manual contains the following instructions that should be strictly followed at all times to prevent injury to yourself and other persons as well as damage to property. ■ Safety advisories are categorized and depicted in this manual as follows: DANGER Highly likely to cause death or serious injury.
  • Page 4 We recommend seeking the assistance of an experienced watch technician for sizing of your watch. If adjustment is not done correctly, the bracelet may unexpectedly become detached leading to loss of your watch or injury. Consult your nearest authorized Citizen Technical service center.

  • Page 5: Table Of Contents

    Contents Product features …………………………………………………58 Request for The Citizen Customer Card …………………………60 The CITIZEN Service System ………………………………………62 Handling the Watch ………………………………………………68 Component identification ………………………………………………………68 About the crown and button ……………………………………………………69 Crown position and operation …………………………………………………70 Adjusting the time ………………………………………………………………71 Adjusting the calendar …………………………………………………………73...
  • Page 6 Adjusting the time difference …………………………………………………78 Checking the reference position ………………………………………………80 Performing the "all reset" procedure ……………………………………………82 Recharging your watch …………………………………………………………84 Troubleshooting …………………………………………………88 Timekeeping accuracy ……………………………………………89 Precautions ………………………………………………………90 Specifications …………………………………………………… 100 Customer Support Center …………………………………… 102...

  • Page 7: Product Features

    Further, we offer long-term warranty (10 years) and long-term maintenance services for extra reassurance. Other features include the following: Eco-drive Eco-drive is a unique technology of Citizen that uses light to generate power, thus eliminating the need for periodic battery replacement. 12 o'clock midnight sharp calendar update function The calendar updates as the clock strikes midnight (0:00:00).
  • Page 8 Product features Perpetual calendar No need for date correction at the end of each month. The leap year is also updated automatically. (until February 28th, 2100) JIS1 antimagnetic performance The functionality of the watch will be maintained even when the watch is brought as close as up to 5 cm of the devices that emit magnetic fields in daily life.

  • Page 9: Request For The Citizen Customer Card

    Please direct any inquiries regarding customer registration and customer card to the Citizen Technical Service Center. * The personal information provided on this card will be maintained under strict control by Citizen Watch Co., Ltd. and the authorized service centers and will be used solely for the purpose of providing after-sales service for The Citizen products purchased.
  • Page 10 Request for The Citizen Customer Card ◆ The CITIZEN customer registration card (example) Back-cover engraving The back-cover (example) The refer to it when filling out the case number and the serial number on your customer card. * Display location may differ with...

  • Page 11: The Citizen Service System

    We will repair all spontaneous failures of the watch free of charge for ten years after purchase. Should failure occur during the warranty period, under normal use as prescribed by the instruction manual, please send the watch and your card type warranty directly to the Citizen Technical Service Center, or via the place of purchase.
  • Page 12 To ensure your continued enjoyment of this watch, we are offering two inspections, free of charge, over the course of the first ten years after purchase. The Citizen Technical Service Center will provide the details when the inspections are due.
  • Page 13 20 years, after the expiration of the 10-year warranty. All repairs to The CITIZEN, both during and after its warranty period, will be performed at the Citizen Technical Service Center by highly trained technicians (meisters), who use techniques acquired over many years, along with a wealth of experience and ingenuity, to offer our customers user-friendly maintenance and services.
  • Page 14 The CITIZEN Service System At the Citizen Technical Service Center, all watches have their history (data) stored and referenced during repairs, a unique system which ensures adequate repair services. However, in some instances it may become necessary to replace exterior parts such as the case,...
  • Page 15 The CITIZEN Service System We provide a 10-year warranty, free inspections, as well as meticulous after-sales services. Process for issuing The CITIZEN CUSTOMER CARD (a card type warranty) Request for Receipt of Verification Product Customer customer card customer of enclosed...
  • Page 16 Inspection examination Customer End of inspection sheet (to fill out) Please attach to the watch. Note : In case of inconvenience, please contact the Citizen Technical Service Center or the place of purchase. We will be responsible for the sending charge.

  • Page 17: Handling The Watch

    Handling the Watch ◆ Component identification Button Minute hand Charge indicator Crown Second hand Date indicator Hour hand * The illustrations may differ from the actual watch you have purchased.

  • Page 18: About The Crown And Button

    Handling the Watch ◆ About the crown and button Some models feature a screw down crown and/or screw down push button. Locking the crown and/or button prevents accidental operation. These must be unlocked prior to using certain features of your watch such as setting the time or date. Unlock Lock Screw down...

  • Page 19: Crown Position And Operation

    Handling the Watch ◆ Crown position and operation Pull the crown out to make necessary adjustments, as illustrated below. Position (default position): No adjustment can be performed. Position : For adjusting time difference and calendar Position : For adjusting time * The screw down lock returns to position when unlocked.

  • Page 20: Adjusting The Time

    Handling the Watch ◆ Adjusting the time Adjust the time with the crown set in Position * If the second hand is moving in two-second increments (insufficient charge warning), charge the watch first (see page 86). With the second hand at the 12 Rotate the crown to set the time.
  • Page 21 Handling the Watch ◆ Adjusting the time Continued Return the crown to Position to complete the setting. • Use the time signal, etc. to push the crown into Position the right timing. (In case of a screw down crown, lock the crown. See page 69.) Continued from previous page Position...

  • Page 22: Adjusting The Calendar

    Handling the Watch ◆ Adjusting the calendar Adjust the calendar (date/month/year) with the crown set in Position * If the second hand is moving in two-second increments (insufficient charge warning), charge the watch first (see page 86). Pull the crown out to Rotate the crown to set the date.
  • Page 23 Handling the Watch ◆ Adjusting the calendar Continued Hold down the button for two seconds. • The second hand moves to show the current month and year. For details on how to read the month and year, see page 76. Continued from previous page Position...
  • Page 24 Handling the Watch Press the button to adjust the month and year. Return the crown to Position complete the setting. • The second hand moves forward in one-minute marker (In case of a screw down crown, lock increments with every pressing of the button. the crown.

  • Page 25: Month And Leap Year Indications

    Handling the Watch ◆ Month and leap year indications When the time and date are corrected manually, the elapsed years from the most recent leap year and the month are indicated at the position of the second hand. Nov. Dec. •...
  • Page 26 Handling the Watch Quick reference chart for number of years passed since leap year Indication of the second hand Passed year Year Hour marker Leap year 2016, 2020, 2024 1st min. marker 1st year 2013, 2017, 2021 2nd min. marker 2nd year 2014, 2018, 2022 3rd min.

  • Page 27: Adjusting The Time Difference

    Handling the Watch ◆ Adjusting the time difference When you travel overseas, you can easily adjust your watch to the local time without having to stop the watch. The adjustment can be made in one-hour increments/decrements. * If the second hand is moving in two-second increments (insufficient charge warning), charge the watch first (see page 86). Pull the crown out to Rotate the crown to correct the time difference.
  • Page 28 Handling the Watch Return the crown to Position to complete the setting. (In case of a screw down crown, lock the crown. See page 69.) • To reset to the original time, rotate the hour hand in a direction opposite to the direction in which it was moved to correct the time difference.

  • Page 29: Checking The Reference Position

    Handling the Watch ◆ Checking the reference position If any of the hands are not aligned at the 12 o'clock position, or if the date indication is misaligned, check the reference position. * If the second hand is moving in two-second increments (insufficient charge warning), charge the watch first (see page 86). Set the crown to Hold down the button (for approximately 5 seconds) until the charge hand begins to move.
  • Page 30 Handling the Watch Check if all hands and date are at the reference position. Press the button to resume the current time indication.Adjust the Hour, minute, and second hands: 12 o'clock position time and calendar (see page 71). Reference Date: 1 position Press the Power reserve indication: Level 3 (see page 84)

  • Page 31: Performing The "All Reset" Procedure

    Handling the Watch ◆ Performing the "all reset" procedure If the watch does not work stably, you can perform the "all reset" procedure. * If you perform all reset, all information will be deleted. Do no perform all reset unless absolutely necessary. * Make sure to charge the watch before performing all reset (see page 85).
  • Page 32 Handling the Watch If you perform all reset, the watch setting is updated as follows: • Calendar: January 1 (leap year) • Time: AM time indicated by the hour, minute, and second hands Adjust the time and calendar (see Return the crown to Position page 71).

  • Page 33: Recharging Your Watch

    Handling the Watch ◆ Recharging your watch This watch has a rechargeable cell which is charged by exposing the dial to light such as direct sunlight or fluorescent lamps. ■ How to check the power reserve indicator The needle position of the power reserve indicator shows the power reserve amount, as illustrated below. Charge level Level 3 Level 2...
  • Page 34 Handling the Watch ■ Charging time by environment Below are the approximate times needed for charging when exposing the watch dial to light continuously. Please use this table as a reference only. Charging time (approx.) Illuminance To become fully Environment To work for To start working normally (lx)
  • Page 35 Handling the Watch ■ For optimal performance For optimal performance, make sure to observe the following precautions: • Place the watch under direct sunlight and charge it for 5 to 6 hours at least once a month. • After taking off the watch, place it in a well-lighted place or by the window where sunlight shines in. •...
  • Page 36 Handling the Watch ■ Power save feature If you store the watch inside the case or other dark places where no light can reach the dial of the watch for seven consecutive days or longer, the watch will automatically stop at the 12 o'clock position to save battery power.

  • Page 37: Troubleshooting

    Charge the watch by exposing it to direct sunlight for five to six hours. If the immediately after it has been problem still persists, contact the shop where you made the purchase, or your fully charged. nearest Authorized Citizen Service Center listed in your warranty booklet.

  • Page 38: Timekeeping Accuracy

    Timekeeping accuracy This watch has 5-second accuracy per year. ■ To maintain 5-second accuracy per year To maintain this timekeeping accuracy, you must use the watch at ambient temperature (between +5°C and +40°C) and carry it with you approximately 12 hours a day. Please bear in mind that, if the watch is used under any other conditions, the accuracy may be compromised.

  • Page 39: Precautions

    Precautions ◆ Eco-Drive Watch Handling Precautions <Always make sure to recharge frequently> • Please note that if you wear long sleeves, the watch may stop as a result of being covered by your sleeve and blocked from the light. • When you take off the watch, try to place it in as bright a location as possible. This will ensure that it will continue to run properly.
  • Page 40 Precautions <Replacement of Rechargeable Cell> • Because the watch uses a rechargeable cell, you do not need periodical cell replacement. However, power consumption may increase after using for an extended period of time due to deterioration, and the power may run out earlier than expected.
  • Page 41 Precautions ◆ Water resistance WARNING Water Resistance • Refer to the watch dial and the case back for the indication of the water resistance of your watch. while skin diving, but not while scuba or saturated diving using helium gas. The following chart provides examples of use for reference to ensure that your watch is used properly.
  • Page 42 Precautions • Upgraded water resistance for daily use (to 5 atmospheres) means that the watch may be worn while swimming, but is not to worn while skin diving. • Upgraded water resistance for daily use (to 10/20 atmospheres) means that the watch may be worn while skin diving, but not while scuba or saturated diving using helium gas.
  • Page 43 Precautions CAUTION To avoid injury • Be particularly careful when wearing your watch while holding a small child, to avoid injury. • Be particularly careful when engaged in strenuous exercise or work, to avoid injury to yourself and others. • Do NOT wear your watch while in a sauna or other location where your watch may become excessively hot, since there is the risk of burns.
  • Page 44 Precautions • Even if your watch has a high level of water resistance, please be careful of the following. - If your watch is immersed in sea water, rinse thoroughly with fresh water and wipe with a dry cloth. - Do not pour water from a tap directly onto your watch. - Take off your watch before taking a bath.
  • Page 45 If adjustment is not done correctly, the bracelet may unexpectedly become detached leading to loss of your watch or injury. Consult your nearest authorized Citizen Technical service center. <Temperature> • The watch may stop or the function of the watch may be impaired in extremely high or low temperature. Do not use the watch in places where the temperature is outside the operating temperature range as stated in the specifications.
  • Page 46 Precautions <Strong Shock> • Avoid dropping the watch or subjecting it to other strong impact. It may cause malfunctions and/or performance deterioration as well as damage to the case and bracelet. <Static Electricity> • The integrated circuits (IC) used in quartz watches are sensitive to static electricity. Please note that the watch may operate erratically or not at all if exposed to intense static electricity.
  • Page 47 Precautions CAUTION Always keep your Watch Clean • Rotate the crown while it is pressed in fully and press the buttons periodically so they do not become stuck due to accumulations of foreign matter. • The case and band of the watch come into direct contact with the skin in the same manner as undergarments. Corrosion of the metal or unnoticed soiling such as that caused by perspiration and dirt can soil sleeves and other portions of clothing.
  • Page 48 Precautions Caring for Your Watch • Wipe any dirt or moisture such as perspiration from the case and crystal with a soft cloth. • For a metallic, plastic or rubber (urethane) watchband, wash any dirt off with water. Remove the small amounts of dirt trapped between the crevices of the metallic band with a soft brush. •...

  • Page 49: Specifications

    Specifications Model A010 Type Analog solar-powered watch Timekeeping Within ±5 seconds per year when worn at normal operation temperatures accuracy (between +5˚C and +40˚C) Operating −10˚C to +60˚C temperature range Display functions Time: Hours, minutes, seconds / Calendar: date / Charge level Continuous •...
  • Page 50 Additional • Solar power function functions • Power reserve indication • Overcharging prevention function • Insufficient charge warning function (2-second interval movement) • Energy saving function (power save feature) • Perpetual calendar (until February 28th, 2100) • JIS1 antimagnetic performance •...
  • Page 51 Other service Citizen Consumer Help Desk 0120–78–4807 TEL: Business hours: 9:30–17:30 (Monday thru Friday excluding holidays) All relevant information can be found in the “ サポート ” section of out web site. http://citizen.jp/ URL:...
