Summary of Contents for Bolide SVR9000S-T4MO
-
Page 2: Table Of Contents
User Manual CONTENTS Important Safeguards ................................1 Chapter 1 Features and Functions ............................2 1.1 Video / Audio ................................2 1.2 Power supply ................................2 1.3 Record Mode ................................2 1.4 Data storage and backup ............................2 1.5 Anti-shock and anti-vibration structure design ....................... 2 1.6 Other .................................. - Page 3 User Manual 5.3.4 Video Search ............................15 5.3.5 Device Management ..........................16 5.3.5.1 HDD Management .......................... 16 5.3.5.2 Alarm Setup ............................ 17 5.3.5.3 Motion Detection ..........................18 5.3.5.4 Vehicle Setup ..........................18 5.3.5.5 PTZ Setup ............................18 5.3.6 System Setup ............................19 5.3.6.1 Time Setup ............................
-
Page 4: Important Safeguards
User Manual Important Safeguards This equipment should be installed with care. Quick stops and excessive force may cause the equipment to damage or overturn. Never push objects of any kind through openings of this equipment and / or spill liquid of any kind on the equipment as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. -
Page 5: Chapter 1 Features And Functions
User Manual Chapter 1 Features and Functions 1.1 Video / Audio ● H.264 video compression format, and supports D1, HD1 and CIF recording format. ● A DPCM audio compression format. 1.2 Power supply ● Support wide range of power supply, DC 9V~32V.； ●... -
Page 6: Chapter 2 Appearance
User Manual Chapter 2 Appearance 2.1 Front Panel 1. Retractable HDD Box 2. Retractable HDD Box Key / Power on/off 3. USB 2.0 Port 4. Indicator a. PWR Indicator: light on when power is on b. HDD Indicator: light on when HDD is available; light flash when HDD is writing data. c. -
Page 7: Rear Panel
User Manual 2.2 Rear Panel Power Supply Jack WIFI Antenna Port Ethernet Port IR-Ext input GPS Antenna Port A/V Jack Cellular Antenna Port Sensor I/O Port 2.3 External Cable and Cord 2.3.1 Power Cord BATT Pin (Red): Power input (connected to car battery+) GND Pin (Black): Power GND (connected to car battery -) ACC Pin (Yellow): Ignition signal input (connected to car power level) The 6-pin plug will be connected to power supply jack of rear panel. -
Page 8: A/V Cable
User Manual 2.3.2 A/V Cable 1. Audio output (white BNC port) 2. Video output (Black BNC port) 3. CH4 Audio input (White BNC port) 4. CH4 Video input (Black BNC port) 5. CH3 Audio input (White BNC port) 6. CH3 Video input (Black BNC port) 7. -
Page 9: I/O Cable
User Manual 2.3.3 I/O cable I/O cable port definition Port Name Description 485 Port RS485 8 Pin: RS485A / 15 Pin: RS485B Alarm input SENSOR1~4 4-CH alarm input 4-CH alarm input, can act as emergency button. Alarm input SENSOR5~8 Alarm output ALARM0~1 2-CH alarm output Speed... -
Page 10: Alarm I/O
User Manual 2.3.4 Alarm I/O The device connected to eight groups of alarm input and two groups of alarm output. When brake plate is stepped on illustrated in below Picture, mobile DVR can detect high level. Alarm output belongs to level output and driving capacity is 200 MA. If driving power is too strong, the relay is required. -
Page 11: Chapter3 Connecting Dvr
User Manual 2.4 Remote Controller Key Function Key Function Key Function Key Function title title title title Channel select CH1~CH4; numeric key Channel select CH1~CH4; numeric key Channel select CH1~CH4; numeric key Channel select CH1~CH4; numeric key numeric key numeric key numeric key numeric key 0、... -
Page 12: Removeable Hdd Installation
User Manual 2. Take the device away from the anti-vibration rack. 3. Install anti-vibration rack to vehicle with screws. 4. Fix the device back the anti-vibration rack with previous three screws. 5. Finish the device installation. 3.2 Removeable HDD installation Please follow the below steps to install the HDD: Take out removable HDD from the HDD box;... -
Page 13: Connecting Power Supply
User Manual 3.3 Connecting Power Supply The 6-pin plug will be connected to power supply jack of rear panel. Red and black wires connected to car battery + and – respectively, yellow wire to ignition wire. Reminder: 1. MDVR use DC power supply, please connect it properly; 2. -
Page 14: Chapter 4 Starting The System
User Manual Chapter 4 Starting the system 4.1 System Initialization Connect the power cable of DVR to power supply and press the [Power] button, you will see the initialization screen shown as below 4-1. Picture 4-1 4.2 Main Interface After finishing the initialization processing, system will enter into Main interface screen. -
Page 15: Chapter 5 Dvr Menu
User Manual Chapter 5 MDVR Menu 5.1 Context-Sensitive Menu On the Main Interface mode, Press [SEL] key on the Remote Controller to pop up a Context Sensitive Menu. Now you could perform parameter setting and control for Main Menu, Menu Lock, Video Search, Start Record, Stop Record and PIP Mode etc. -
Page 16: Main Menu
User Manual 5.3 Main Menu In Main Interface mode, click right key of mouse to pop up Context Sensitive Menu, and then highlight and select [Main menu] item to enter into Main menu. Now user can freely set parameters for [Camera], [Record], [Network], [Search], [Device] and [System] as per user’s needs. -
Page 17: Network Setup
User Manual The [Record Setup] menu allows you set up recording status (on/off) of each channel, it also allows you setup recording image resolution and quality, and turn audio on/off. Channel： ： ： ： Once a channel is set to “on” the channel can record, and is set to “off” the video from the channel will not be recorded Resolution: include three options –... -
Page 18: Video Search
User Manual All the parameters you set are available only when you click [Ok] and after system is restarted. Enter into the [Network set] interface again and [State] column will display the characters “Connecting” shown as Picture 5-9. The 3G dialing will be successful till one IP code appear on the [State] column. -
Page 19: Device Management
User Manual Prev: go to the previous ones of current page. Clicking [Pre] button will take you back the previous ones of current page (except the first page). Next: go to the next ones of current page. Clicking the [Next] button will take you to the next ones of current page (except the last page). -
Page 20: Alarm Setup
User Manual auto-reboot function even if system has detected NO DISK FOUND. Overwrite-When set to ENABLE the DVR will record over the oldest files on the hard drive. This is the default setting. And probably the most useful, as the DVR will record the events as they happen. However, it does mean that you’ll get import events off the DVR before they’re overwritten. -
Page 21: Motion Detection
User Manual Alarm Type Function Sends alarm when DVR can’t receive video signal (such as camera damage, cable broken Video Loss Video Loss Video Loss Video Loss or damaged or power supply malfunction). Motion Motion When an object moves into motion detection area, alarm will be triggered. You can Motion Motion Detection... -
Page 22: System Setup
User Manual Enter into [Main menu Device PTZ Setup] to select the channel you wish to control and set PTZ protocol (Pelco-D or Pelco-P), Baud Rate fixed (9600), Data bit (8), Stop bit (1), Parity Check (None) and Address Code respectively. Please make sure the above mentioned channel settings must match with the settings of the PTZ camera. -
Page 23: Video Setup
User Manual 5.3.6.3 Video Setup Click [Main Menu System info Video Setup] to enter into the below interface shown as Picture 5-28. Herein user can set video system (PAL, NTSC); and volume setup as well. Note: the above setting is available after system restart. Click [Volume setup] button to enter into the below picture 5-29. -
Page 24: Menu Lock
User Manual 5.4 Menu Lock Considering a system safety feature you can click [SEL] button on the remote controller to lock system interface when leaving the DVR. Note: The [Menu Lock] function will be available only when user have set user password. Detail please refer to the section 5.3.6.2 Picture5-34 Picture 5-36... -
Page 25: Chapter 6 Ext2 Drive
User Manual Chapter 6 EXT2 Drive You must firstly install EXT2 setup before you backup the removable HDD via USB cable or playback HDD data via Net-viewer on PC. 6.1 System requirement Compatible system: Windows xp/vista/win7 Basic hardware configuration: CPU: Pentium 4 processor (2.0GHz or above) / Memory: 1GB or above 6.2 EXT2 Setup It is recommended that you close all other application before the setup. -
Page 26: Record Export Software
User Manual Picture 6-3 5. After finishing installation, you need to restart the computer. Please click [OK] button to restart the computer. Note: If you can’t normally install the EXTSetup.exe on Vista or Win7 system, please right-click the program to enter into its [Options] menu shown as Picture 6-4 Tick-select the [Compatibility mode] option and click [Apply] and [Confirm] button. - Page 27 User Manual 1. Run the NvrExport.exe in the “Export_tool” file 2. If you want to export all the directory, please tick-select [Directory] option, and export all the files, tick select [File] option shown as Below. When user need to export one day’s record, please select [Directory] option, and export some hours’...
-
Page 28: Chapter 7 Net Viewer Program
User Manual Chapter 7 Net Viewer Program 7.1 How to install Net Viewer program （1） Insert the software CD into your CD-ROM drive; （2） Open the CD file; （3） Double-click the setup file to run the installation program; （4） Follow up the instruction to finish the installation step by step. （5）... - Page 29 User Manual Enter into and select the file you want to playback shown as Picture 7-4. Picture 7-4 Highlight and open the file you desire to playback shown as Picture 7-5 Picture 7-5 Now the record file has been added to the interface shown as Picture 7-6.
- Page 30 User Manual On the playback mode, select one record file and click [Play] button to playback the backup record shown as Picture 7-9. Now you can control its processing through the play control-bar on the bottom of the screen. Slide the volume control bar to adjust the volume. Select one record file and click [Delete] button to delete the file.
-
Page 31: Chapter 8 Specifications
User Manual Chapter 8 Specifications DEVICE SPECIFICATION PARAMETER Video System NTSC / PAL(Optional) Compression Video: H.264 ; Audio: 8kHz*16bit ADPCM Format Video Input 4-CH Input / 1-CH output /Output Audio Input 4-CH Input / 1-CH output /Output Display D1：704×576(PAL) 704×480 (NTSC) Resolution Frame rate Single CH PAL：25 fps ，NTSC：30 fps... - Page 32 User Manual A: Check camera video cable and connections; or check monitor video cable and connections; or confirm that the camera has the power and / or check camera lens setting. Q: Why some channels display just a blank screen even if they receive video sources? A: Check if the camera is connected to the system properly displays the image;...
-
Page 33: Accessories（Optional
User Manual 8.2 Accessories（ （ （ （ Optional） ） ） ） Remote Controller Software CD User Manual Alarm I/O Cable Power Cord Two Keys A/V Cable GPS Mould Antenna（Optional） EVDO Mould Antenna(Optional） Triple-headed USB data cable... - Page 34 User Manual The material in this document is the intellectual property of our department . No part of this manual reproduced, copied, translated, transmitted, or published in any form or by any means without our department prior written permission. Our products are under continual improvement and we reserve the right to make changes without notice.
