  • Page 1 User Manual for GPS/3G/4G, 4/8ch,D1,Hard Disk Mobile Digital Video Recorder(MDVR) MVR9004/8 Model:...

  • Page 2: Table Of Contents

    Hard Disk Mobile DVR User Manual V2.2 Catalogue 1. PRODUCT SPECIFICATION ..........................4 1.1 P ..............................4 RODUCT VERVIEW 1.2 K ................................4 EATURES 1.3 MDVR 1 ........................ 4 DETAIL SPECIFICATIONS TO SEE ABLE 1.4 MDVR 2 ......................6 ELECTRIC PECIFICATIONS TO SEE ABLE 1.5 P...
  • Page 3 Hard Disk Mobile DVR User Manual V2.2 6.2 S ..............................33 PEED ETTINGS 6.3 G-S ..............................33 ENSOR ETTINGS 6.4 T ............................... 34 EMPERATURE ALARM 6.5 M ..............................34 OTION ETECTION 6.6 L ..............................35 INKAGE ETTINGS 6.7 O ................................ 35 THER LARM 7.

  • Page 4: Product Specification

    Hard Disk Mobile DVR User Manual V2.2 1. Product Specification 1.1 Product Overview Hard Disk Mobile DVR (Automotive) is a cost-effective, multi-functional device designed for video surveillance and remote monitoring of your mobile assets. It uses a high-speed processor, an embedded Linux platform, and the most advanced technology in the IT field, such as H.264 Video Compression/Decompression, 3G/4G network transmission technology and GPS positioning technologies.
  • Page 5 Hard Disk Mobile DVR User Manual V2.2 Video Video Signal PAL,NTSC Video Compression H.264 Main profile PAL:100fps at D1, NTSC: 120fps at D1 4CH/8CH Audio input.( Software supports simultaneous Audio input open 2 Audio) Audio Audio output 2 CH Audio output Recording mode Audio &...

  • Page 6: Mdvr Electric Specifications To See Table

    Hard Disk Mobile DVR User Manual V2.2 Center vehicle management software platform, it can manage more than 20000 devices at same time, if need to manager more units, add more servers to realize it. Software Support Flash disk to upgrade the firmware. Upgrade 1.4 MDVR electric Specifications to see Table 2 Table 2: MDVR Electric Specifications...

  • Page 7: Appearance Of Product

    Hard Disk Mobile DVR User Manual V2.2 Figure 1-1 MDVR Schematic diagram 2. Appearance of Product 2.1 Device Appearance...

  • Page 8: Device Drawing Dimension & Install Holes

    Hard Disk Mobile DVR User Manual V2.2 2.2 Device drawing Dimension & Install Holes...

  • Page 9: Front & Back Panel Led & Plug-In Module

    Hard Disk Mobile DVR User Manual V2.2 2.3 Front & Back Panel led & Plug-in module. 4ch and 8ch MDVR Front 4ch and 8ch MDVR Front Table 3 : Front Panel definition Interface Items Description Video out AV-OUT Video Audio and 12V out analog output Recording LED , light on when recording Alarm LED, light on when device work abnormally...

  • Page 10: Back Panel Interface Definition

    Hard Disk Mobile DVR User Manual V2.2 When device is working unlock the E-key, Electronic LOCK system will power off ,lock the E-key .system will work normally USB Port USB 2.0 Upgrade and Export video data 2.4 Back Panel interface definition 4CH MDVR Back 8CH MDVR Back...
  • Page 11 Hard Disk Mobile DVR User Manual V2.2 4CH MDVR Back signal definition diagram Table 4: Back panel interface Definition Table Interface Items Description 3G/4G Antenna Interface 3G/4G 3G/4G Antenna Interface GPS Antenna Interface GPS Antenna Interface Power Input Interface POWER Power input interface Serial AV-out...

  • Page 12: Power Cable

    Hard Disk Mobile DVR User Manual V2.2 2.5 Power Cable Power cable as picture 9,one end is 6pin white plug , it connect with the 6pin white plug of device back panel. The red and black cables are directly connect to the vehicle's battery. Red cable connect to positive , black cable connect to negative .

  • Page 13: Gps Antenna And 3G/4G Antenna

    Hard Disk Mobile DVR User Manual V2.2 2.6 GPS Antenna and 3G/4G Antenna 2.7 Alarm input and output The device has 8 alarm input and 2 alarm output interfaces. Alarm input detection is level detection. Various state of alarm level can be detected while the vehicle is in motion, such as braking, steering horn etc.
  • Page 14 Hard Disk Mobile DVR User Manual V2.2 Table 5: Packing List Hard Disk Mobile DVR-JH4 Packing List Item Specifications Unit Host Machine Accessories Box Power Line-6PIN 6PIN Big557 L=200mm Alarm Line-24PIN AMP24PIN , L=200mm Remote Control HDD/SSD Case （According to 4PIN connector, convert...
  • Page 15 Hard Disk Mobile DVR User Manual V2.2 8CH wiring, A is the first CAM,B is the second B HDD/SSD,SIM card, SD card installation Unlock by the key, insert the HDD/SSD into the HDD/SSD slot in front of the mainframe. Notice: if draw out The HDD/SSD, the front part of HDD/SSD should has a space of over 10cm(the length of HDD/SSD)
  • Page 16 Hard Disk Mobile DVR User Manual V2.2 PLUG THE HDD/SSD-BOX Plug the HDD/SSD box, shrapnel and the handle pressed...
  • Page 17 Hard Disk Mobile DVR User Manual V2.2 Note when the HDD/SSD is installed SIM card is located on the communication board, move the small baffle at the bottom of the mainframe, you can see the interface of SIM card . If system support wireless network communication, need install SIM card.

  • Page 18: Remote Control Function Instruction

    Hard Disk Mobile DVR User Manual V2.2 3. Remote Control Function Instruction 3.1 Remote Control There is no control button on MDVR panel, need remote control to fit operating Key-press & function as below: Digit keys zone： 【0－9】key：Under setting, use for select digit. During playback and preview,1,2,3,4 is for the switch of the channels 【＋】,【－】key：adjust digit when plus or deduct or delete 【ENTER】key：under setting, means select and save...
  • Page 19 Hard Disk Mobile DVR User Manual V2.2 Table 6 : Function keys on remote control Startup/power off Through screen, press this button twice for reboot（soft start key） （note：can’t be use now） LOGIN When setting password, press LOGIN input password. Do please remember password due to device have no reset function.

  • Page 20: Text Input

    Hard Disk Mobile DVR User Manual V2.2 3.2 Text Input 3.3 Video settings...

  • Page 21: Ptz Connection Way And Setting

    Hard Disk Mobile DVR User Manual V2.2 3.4 PTZ connection way and setting...

  • Page 22: Pc Playback Of The Video File

    Hard Disk Mobile DVR User Manual V2.2 3.5 PC playback of the video file You must install “Ext3 format driver of HDD”(Ext2Fsd-0.51) when you read HDD on your computer first. Double-click installation files within MDVR Player ***. Exe, and then select the installation language, support Chinese and English, and click "OK"...
  • Page 23 Hard Disk Mobile DVR User Manual V2.2 Account: admin password:000000 Connect Hard disk to the computer's USB port, the computer automatically recognizes the newly installed hard drives, video files are stored in the form of the date folder, open the folder and display video files, video files named suffix ".

  • Page 24: Fast Report By Vehicle Server

    Hard Disk Mobile DVR User Manual V2.2 3.6 Fast report by vehicle server Step 6: These are networked into the way when connected to the network, the next step is in the CMS management software on the PC operation, the two steps: If you are self-built server, the client account and add their own vehicles and assigned vehicles;...
  • Page 25 Hard Disk Mobile DVR User Manual V2.2...

  • Page 26: General Settings

    Hard Disk Mobile DVR User Manual V2.2 4. General settings General settings is the first menu in system menu, the generic setting interface contains four function options: date and time, vehicle information, user management and network. 4.1 Date & Time Set the system time and some other basic properties of the device 1．Date Format: Press "ENTER"...

  • Page 27: Vehicle Settings

    Hard Disk Mobile DVR User Manual V2.2 recording by the delay off set time before shutting down when the vehicle is turned off. 7. Auto Maintenance function: when the MDVR work more than 24hours. setup ON, give it a time, MDVR will automatically restart to work properly, this need about 50 seconds.

  • Page 28: Network Settings

    Hard Disk Mobile DVR User Manual V2.2 4.4 Network Settings Network setup interface 1.IP address Mask Gateway etc. are LAN network setting after plugging in the network cable, there is no need to input if you do not use them. 2.Net Mode: IP: Server use Static external network IP；...

  • Page 29: Main Code

    Hard Disk Mobile DVR User Manual V2.2 3. Selectable packet time: 15/30/45/60 minutes, which stands for the time period how long the video file will become a packaged file. 4. Automatically overwritten can be selected to on / off, when on, the previous video files will be automatically overwritten if the hard disk space is less than 2G as well as the mirror video disk &...

  • Page 30: Sub-Stream

    Hard Disk Mobile DVR User Manual V2.2 5.3 Sub-stream Description: sub-stream important parameters when video and data are uploaded to the network through 3G/4G, and its settings are related to the clear and smooth watching effect of video on CMS platform, of course, network transmission mostly depends on the uplink and downlink rate of local network.

  • Page 31: Mirror Record(Optional)

    Hard Disk Mobile DVR User Manual V2.2 5.5 Mirror Record(Optional) Description: Mirror record is used as a record backup to prevent record missing issue caused by hard disk error, the parameter setting can refer to the main code parameter settings. Note: The main code plus mirroring video can support 6 full frame D1 record.

  • Page 32: Speed Record(Optional)

    Hard Disk Mobile DVR User Manual V2.2 frame 1-30. 4. Adjustable video quality:1-8. 1 is best. 5. Audio: this can be set whether to open the audio of the record, if on, then the audio will be recorded into the record file. 5.8 Speed Record(Optional) 1.

  • Page 33: Speed Settings

    Hard Disk Mobile DVR User Manual V2.2 etc., they are in effective when sensor input is high level , users generally use higher than 5V high level to trigger alarm. Note: less than 1V is low level. 4. When selecting type to be event, the record file is a normal record. when selecting the type of alarm, the record file type is alarm.

  • Page 34: Temperature Alarm

    Hard Disk Mobile DVR User Manual V2.2 speaking vehicle’s instant acceleration is relatively large in case of slam the brakes on, crash, acceleration and sharp turns, whose intuitive reflection is threshold beating, and PC displays X/Y/Z three states by waveform when playing back. When an alarm is generated, it also can be sent to center CMSServer platform to record alarm information.

  • Page 35: Linkage Settings

    Hard Disk Mobile DVR User Manual V2.2 6.6 Linkage Settings 1. Select the output (output selectable output, output 1, output 2) in the corresponding column. after selecting the output, when an alarm is generated, the corresponding alarm output line will generate 12V high level to drive the work of other equipment.

  • Page 36: Tools

    Hard Disk Mobile DVR User Manual V2.2 7. TOOLS 7.1 Parameter configuration 1. When the device parameters are in confusion, equipment can restore the default configuration to go back to factory settings. 2. Inserting USB storage device to the front USB port, the USB configuration files can be imported into this device.

  • Page 37: Log Search

    Hard Disk Mobile DVR User Manual V2.2 7.3 Log Search Calendar with green background means it has log, log query starts by selecting the date, start time, end time, log type: system log, alarm log. Such as on & off, video loss, parameter setting.

  • Page 38: 4G Settings

    Hard Disk Mobile DVR User Manual V2.2 6 Check: check bit is to select the check way. Generally it is chosen to be None. 7 Address: the address code is input directly by the address corresponding to PTZ setting, they must be setting corresponding to, the default address code of most PTZ is 1.

  • Page 39: Oil Settings

    Hard Disk Mobile DVR User Manual V2.2 1. Select WIFI module to be internal or external. 2. Select enable to be on. 3. Internal WIFI ： Hot switch can support multiple connections. Please refer to the router parameters. External WIFI. Input the IP address of AP-WiFi, note: the device to determine whether the RJ45 interface and external module is connected by IP.

  • Page 40: Record Search

    Hard Disk Mobile DVR User Manual V2.2 9.Record Search Calendar with green background means it has video file, video search starts by selecting the date, start time, end time, record path: hard drive, mirror, card, record type: conventional recording, alarm recording, all recording, channels: all channels, 1-4, 1-8.

  • Page 41: Appendix 1: Cmsserver Platform Interface

    Hard Disk Mobile DVR User Manual V2.2 Appendix 1: CMSServer platform interface Appendix 2: Common problems and treatment Q: What can I do when I found a problem with the product, but I can’t solve it by myself? A: Take note of the model and software version number, then submit a detailed description of the problem to the Technical supporting engineers to analyze.
  • Page 42 Hard Disk Mobile DVR User Manual V2.2 take video when it is not within the video recording time period. 3.Check the SD card inserting status and whether the SD light on front panel is on or not. Q: The video file is missing or there is no video file within a certain period of time, how to do? A: 1.
  • Page 43 Hard Disk Mobile DVR User Manual V2.2 however, there are some mountainous districts without signal coverage, and some suburban areas have weak signal due to the local network constraints, then it will be jammed during watching of video, or video cannot be watched at all, the greatest impact of this situation is from the local network. Moreover check whether the frame rate setting of sub-stream is too high, because the video may also occur such situation when the network is poor and frame rate setting is high.

  • Page 44: Appendix 3:Storage Space Corresponding Table

    Hard Disk Mobile DVR User Manual V2.2 Appendix 3:storage space corresponding table Appendix 4:MDVR Before loading the tool to check Equipment installation before the installation is required to prepare the necessary installation tools, common tool types in the table below: NAME Specification Explanation...

  • Page 45: Appendix 5:Mdvr Before Loading The Installation Of Auxiliary Examination

    Hard Disk Mobile DVR User Manual V2.2 Appendix 5:MDVR Before loading the installation of auxiliary examination Equipment installation before the installation to be complete some of the necessary installation accessories, accessories category in the table below: NAME ICON NAME ICON POWER LINE LINE...
