Ercogener GenPro 25e User Manual

Hide thumbs Also See for GenPro 25e:
Table of Contents

Advertisement

User Guide
GenPro 25e
Reference : EG_GenPro25e_1055_UG_002_UK
Revision : 002
Date :
17/05/2018
http://www.ercogener.com
Dct_427_02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GenPro 25e and is the answer not in the manual?

Questions and answers

Summary of Contents for Ercogener GenPro 25e

  • Page 1 User Guide GenPro 25e Reference : EG_GenPro25e_1055_UG_002_UK Revision : 002 Date : 17/05/2018 http://www.ercogener.com Dct_427_02...
  • Page 2 17/05/2018 31/10/2018 Options presentation. § 3.4.2.2 Consumption of the GenPro 25e. The main modifications of this document compared to the previous version are easily identifiable on a screen by the blue color of the text. Descriptions and non-contractual illustrations in this document are given as an indication only.
  • Page 3: Table Of Contents

    Power supply cables ....................... 22 3.4.2 Power supply +V ........................22 3.4.2.1 Internal battery option (S0431B) ..................23 3.4.2.2 Consumption of the GenPro 25e ................... 24 3.4.2.3 Power Dimensioning ....................... 26 E1, E2 E3 ........................27 NPUTS 3.5.1 Opto-coupled inputs ........................ 27 Analog input 0 –...
  • Page 4 Fixing on a DIN rail ......................50 Waterproof casing – K011 / K012 ................... 51 5.9.2 CLIENT SUPPORT ..........................51 Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 5 ANNEX 1 - 4-PINS MICRO-FIT CABLE (POWER SUPPLY) ................. 52 ANNEX - 2-WIRE MICRO FIT CABLE CONNECTOR (INPUT/OUTPUT) ............. 53 ANNEX 3 - ABBREVIATIONS ........................54 Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 6 Table 40 : Status of GSM LED with S0502A option ..................40 Table 41 : Characteristics of GSM external antenna ..................41 Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 7 Table 47 : Characteristics of 2-wire Micro FIT cable ..................53 Table 48 : Wiring of 2-wires cable ........................53 Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 8 Figure 33 : Fuse Mini Blade ..........................52 Figure 34 : 2-wire Micro FIT cable connector (Input/Output) ................53 Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 9: Presentation

    ▪ Specific development mode: the EGM development tool allows the development of a customized application. For more information about the tools and trainings, please contact our sales department. The GenPro 25e provides digital inputs/outputs allowing the creation of embedded telematic solutions with high added value.
  • Page 10: Warning

    - In order to avoid any risk of electrocution, do not open the casing. - For any functioning, the casing must be closed. - No internal part can be repaired by the user. The GenPro 25e must be returned to the factory for any repair the RMA request (Return Material Authorization).
  • Page 11: Copyright

    ERCOGENER reserves the right to revise or withdraw this document at any time and without previous notice.
  • Page 12: Security Recommendations

     The modem must be used at more than 20cm from the human body. This equipment is supplied in Very Low Security Voltage and at non-dangerous energy level. Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 13: Security In A Vehicle

    Do not place the modem next to computer disks, credit or travel cards or other magnetic supports. The information contained on disks or cards can be affected by the modem. The use of other equipment or accessories not made or not authorized by ERCOGENER can cancel the guarantee of the modem.
  • Page 14: Packaging

    - Width ..: 54.5 mm, - Height ..: 68 - Length ..: 108 - Weight ..: 190 Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 15: Mechanical Characteristics

    Modem fixing 2 brackets are used to fix the modem on a support. Figure 3 : Fixing Fixing brackets Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 16: Characteristics And Services

    2.4 Characteristics and Services 2.4.1 Services The GenPro 25e is a modem GSM/GPRS class10 dedicated to the transmission of binary data in asynchronous, SMS. The modem characteristics and the available services are summarized in the table below. Table 2 : Characteristics and Services Functions 2G GSM / GPRS / EDGE •GSM/GPRS Protocol Stack 3GPP Release 99...
  • Page 17 * These options are in addition or replace some existing options, contact us (see § 3.3.2 Functional architecture of option) Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 18: Environmental Characteristics

    When the temperature exceeds 45 °C inside the box, the protection of the battery management triggers. The battery will not be charged. Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 19: Interfaces

    105 – DPE – RTS Request to send 125 – IA – RI Call indicator Reset RESET Loudspeaker - SPK- Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 20: Back Side

    Page 20 / 58 3.2 Back side Figure 5 : Back side Connector SMA-F GSM antenna GSM LED SIM card cover Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 21: Functional Description

    Functional architecture of option Contact us for the setting of the different options. Figure 7 : Architecture of option Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 22: Power Supply

    3.4.1 Power supply cables The modem is powered with the cable supplied with the equipment (ERCOGENER reference: 4402304215). (See ANNEX 1 - 4-pins Micro-FIT cable (Power supply)) The modem is protected by a fuse F2 A / 32 V directly assembled on the power cable supplied with the modem.
  • Page 23: Internal Battery Option (S0431B)

    Page 23 / 58 3.4.2.1 Internal battery option (S0431B) This battery allows to maintain the operation of the GenPro 25e in case of absence of its external power supply. The internal charging circuit keeps the battery charge permanently from the external power supply.
  • Page 24: Consumption Of The Genpro 25E

    Average I nominal Unit. GSM / GPRS The GenPro 25e is in Low Power mode with the command AT+EGLOP=1,xx. The GenPro 25e is attached to the network. Table 9 : Consumption in attached mode @ 25 °C without battery charging Mode attaché...
  • Page 25 Unit. GSM / GPRS The GenPro 25e is in Low Power mode with the command AT+EGLOP=1,xx. The GenPro 25e is attached to the network. Table 12 : Consumption in attached mode with option S0502A @ 25 °C without battery charging Attached mode Unit.
  • Page 26: Power Dimensioning

    Figure 8 : Consumption max This consumption is not permanent. It corresponds to the burst consumption during GSM communications. Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 27: Inputs E1, E2 And E3

    Figure 9 : internal electrical scheme of the 3 inputs The minimum command voltage for the detection is: 3,5 V The maximum command voltage is: 35 V Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 28: Analog Input 0 - 10 V (Option S0434B)

    The integrator has the responsibility to protect the input from electric disturbances and to respect the values of the functioning parameters. Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 29: Bus One-Wire (Option S0433B)

    The integrator has the responsibility to protect the input from electrical perturbations and to respect the functioning parameters values. Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 30: Multi One-Wire Bus (Option S0485B)

    The integrator has the responsibility to protect the input from electrical perturbations and to respect the functioning parameters values Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 31: Digital Outputs

    Figure 13 : Internal electrical scheme of the output No protection is ensured. The user must respect the values of the table below. Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 32: Serial Link Rs232C

    Resistance ground RS-232 Output Short-Circuit ±15 ±60 Current Figure 14 : Normalized signals of a RS232C serial link Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 33: Transparent Mode Option (S0502A)

    The signal RI indicates with its rhythm either an incoming call or the reception of a SMS. Figure 16 : Status of RI signal Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 34: Option Output +3,8V

    When the battery is not connected, the output voltage is de 4.4V ≤ Vout ≤ 4.5 V as long as the power supply +VDC is present Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 35: Boot

    The integrator has the responsibility to protect the input from electrical perturbations and to respect the functioning parameters values. Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 36: Reset

    The integrator has the responsibility to protect the input from electrical perturbations and to respect the functioning parameters values. Figure 20 : Chronogram of RESET signal Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 37: Audio

    The integrator has the responsibility to protect the inputs from electric disturbances and to respect the adequate values of the functioning parameters. Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 38: Loudspeaker Output (Speaker)

    The integrator has the responsibility to protect the outputs from electric disturbances and to respect the adequate values of the functioning parameters. Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 39: Typical Assembly

    Table 38 : Characteristics of the SIM card power voltage Carte SIM 3 V or 1.8 V Format Mini SIM Standard 2FF / Plug-in UICC (25x15x0,76 mm) Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 40: Led Of The Modem

    0.1s ON / 0.1 s OFF Session TCP/UDP open 3.12.4 The owner application The GenPro 25e contains your application. The led status depends on your parameters. 3.12.5 With Mode Transparent option (S0502A) With this option GSM LED Status is managed by the GSM module.
  • Page 41: Accelerometer Option S0432B

    EG_GenPro25e_1055_UG_002_UK Page 41 / 58 3.13 Accelerometer option S0432B The GenPro 25e provides an accelerometer with 3 axis of sensitivity ±2G or ±8G controllable by software. Figure 24 : Positioning of the accelerometer axis 4 GSM external antenna The GSM external antenna is connected to the modem via le Connector SMA-Female.
  • Page 42: Use Of The Modem

    Page 42 / 58 5 Use of the modem 5.1 Specific recommendations for the use of the modem in vehicles The power supply connector of the modem GenPro 25e must NEVER be connected directly to the battery of the vehicle. 5.1.1 Recommended connection on the battery of a truck All trucks have a circuit breaker outside the cabin.
  • Page 43: Turning The Modem Off

    The switching of the battery and its auto-maintain will be automatically reactivated once the modem will be plugged again to its external power supply. Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 44: Starting With The Modem

    - Push the SIM card until hearing a "clic" that ensures its correct positioning. - Put the SIM cover back. Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 45: Use The Modem

    5.4.1.1 Without Application The GenPro 25e does not contain any application; it will return the menu of the Bootloader. Menu by default when there is no application inside the equipment (example of display) Bootloader V4.11 GP25 UA Gener Ublox (HWF7 rev C)
  • Page 46: With The Transparent Mode Application S0502A

    5.4.1.2 With the transparent mode application S0502A The GenPro 25e contains the transparent mode application S0502A, it is waiting for a command. Connect the RS232 between the DTE (COM port) and the modem (DCE). Set the RS232 port of the DTE as follows: ▪...
  • Page 47: Checking The Quality Of The Gsm Reception Signal

    Above 15, the signal is sufficient.. For more information about the AT commands, see the document "u-blox_AT_Commands_Manual_xxx.pdf Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 48: Verification Of The Pin Code

    - the reception level of the signal (cf. § 5.5 Checking the quality of the GSM reception signal). For more information about the AT commands, see the document "u-blox_AT_Commands_Manual_xxx.pdf" Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 49: Verification Of The Modem Registration On Gprs Network

    - the reception level of the signal (cf. § 5.5 Checking the quality of the GSM reception signal). - the SIM card subscription. For more information about the AT commands, see the document "u-blox_AT_Commands_Manual_xxx.pdf" Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 50: Recommended Accessories

    EG_GenPro25e_1055_UG_002_UK Page 50 / 58 5.9 Recommended accessories The accessories recommended by ERCOGENER for the modem GenPro 25e are described on our website in the section Products/Accessories. For more information, please contact our sales department. DIN-rail Kit – K002 5.9.1 The DIN-rail kit (35mm) K002 allows a quick assembly/disassembly on a DIN Rail (35mm) OMEGA (IEC/EN 60715 / DIN (35mm) 7.5mm).
  • Page 51: Waterproof Casing - K011 / K012

    K011 transparent 6 Client support ERCOGENER ensures the client support for all its modems sold. You will then have access to: The latest version of this document The datasheet of the product The latest versions of the OS user guides...
  • Page 52: Figure 32 : 4-Wires Micro-Fit Cable

    Fuse reference: Mini Blade for automobile 2A - 32V (color code: grey) Figure 33 : Fuse Mini Blade Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 53: Figure 34 : 2-Wire Micro Fit Cable Connector (Input/Output)

    Table 48 : Wiring of 2-wires cable N° Broche Signal Color Input 2 (I2) Yellow Input 3 (I3) Blue Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 54 Data Connection Management Digital Cellular System Display Data Channel (I2C compatible) Interface Down-link (Reception) Domain Name Server Do not use Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 55 Input / Output Inter-Integrated Circuit Interface ICCID Integrated Circuit Card ID ICMP Internet Control Message Protocol Inter Processor Communication Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 56 Pascal (for speaker sound pressure measurements) Packet Assembler/Disassembler PBCCH Packet Broadcast Control Channel Personal Computer Printed Circuit Board P-CID Physical Cell Id Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 57 Sound Pressure Level SRAM Static Random Access Memory Signalling Radio Bearer SUPL Secure User Plane Location Terminal Adaptor Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
  • Page 58 Universal Terrestrial Radio Access Network UUS1 User-to-User Signalling Supplementary Service 1 VSWR Voltage Stationary Wave Ratio WCDMA Wideband Code Division Multiple Access Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER reserves the right to make any modification. Dct_427_02...
