- Page 1 SVR2420 Series Mobile PoE NVRs Installation Guide...
- Page 2 Trademarks ™ Kedacom™, TrueSens™ and are registered trademarks of Suzhou Keda Technology Co., Ltd. in China and various other countries. All other trademarks mentioned in this document are the property of their respective holders. Suzhou Keda Technology Co., Ltd. 131 Jinshan Road...
- Page 3 Keep components in their antistatic packaging until they are installed. Avoid wearing clothing made of wool or synthetic materials. Ensure that an SVR2420 series mobile PoE NVR (hereinafter referred to as the device) is well grounded. Keep the area around the device clean, free of clutter, and well ventilated.
- Page 4 2.2 EMI To shield electromagnetic interference (EMI), you should observe the following guidelines: Keep the ground system of the device away from that of the power supply system or lightning protection system. Place the device away from high-frequency devices, such as radio or radar stations. When necessary, deploy EMI shielding devices.
- Page 5 3. Wear a grounding wrist strap to replace the old battery with the new one. Replacement During replacement, do not mix up the anode and cathode. Contact the local authorized Kedacom agent if you encounter any problem when replacing the battery. Disposal...
-
Page 6: Panel Description
Panel Description 1 Front Panel Location signal indicator Operating status indicator HDD status indicator 4G signal Key hole USB port indicator Wi-Fi status Key slot indicator Ethernet port, 1000M, Adaptive LAN1 (default IP: 192.168.1.100) Figure 1 Front panel of the device... - Page 7 Table 5 Indicator description Description Indicator State The device is started. Blinking The device is operating. Operating (2s on and 2s off) status The device stops operating. The device is connected to the mobile network. 4G signal The device is disconnected from the mobile network. The device works out its location data.
- Page 8 If you connect an ALARM IN cable to a port GND cable, an alarm will be triggered. Audio out Monitoring keyboard KEDACOM The device supports only alarm inputs requiring less than 12 V DC voltage. Alarm output Audio in For alarm outputs, the device supports only...
- Page 9 [Aviation Plugs] 1：TXP_ETH0 2：RXN_ETH0 3：RXP_ETH0 4：TXN_ETH0 1：AV OUT1 1+2+3+4：CAR_IN+ 5+6：NC 1+2：PWR PTZ 4 5 6 7 5：ACC 2：AV OUT2 7：TXP_ETH1 3+4：GND 6+7+8+9：CAR_IN- 3+4：GND 8：RXN_ETH1 9：RXP_ETH1 AV OU T PWR PTZ OUT PWR IN 10：TXN_ETH1 [Alarm Input Port and Extension Port] 13 15 13 15 12 14...
- Page 10 3 Connecting a Handheld Speaker&Microphone to the Device You are advised to use the KEDACOM handheld speakerµphone of model HM-200. You should connect the HM-200 to the following wires of the device. Color AUDIO IN Black Green SPEARKER+ White SPEARKER-...
-
Page 11: Installing The Device
Installing the Device 1 Installing an HDD and a SIM Card You are advised to install an HDD before using the device. If you do not install an HDD: You cannot use the recording function. When the device starts operating and detects that no HDD is installed, the beeper will go off and an alarm will be generated. - Page 12 After the HDD carrier is slid out, you will find SIM card slots 1 and 2 on the left side of the chassis. You can now install a SIM card. If you do not install a SIM card, the device cannot access the mobile network.
- Page 13 To power on the device, turn on your car engine. To power off the device, shut your car engine off. For details on how to use the device, see the user guide inlcuded in the KEDACOM Document and Utility CD.
- Page 14 Activation and Initial Configuration To activate the device through the Internet Explorer: 1. Connect a network cable to the network port on the front panel (default IP of LAN1: 192.168.1.100) of the device. 2. Add an IP address from the 192.168.1.X network segment with the subnet mask being 255.255.255.0 to your PC.
- Page 15 Configuring mobile settings. Configure Session Initiation Protocol (SIP) settings for the device to register with a SIP platform (for example, the KEDACOM VMS). For details on how to initially configure the device, see chatper Getting Started of User Manual for Mobile PoE NVRs.
- Page 16 This page is intentionally left blank.
- Page 17 This page is intentionally left blank.
-
Page 18: What Is Not Covered By This Warranty
Kedacom hardware. Manufacturers, suppliers, or publishers, other than Kedacom, may provide their own warranties to you but Kedacom, in so far as permitted by law, provides their products "AS IS". Software distributed by Kedacom with or without the Kedacom brand (including, but not limited to system software) is not covered by this warranty. -
Page 19: How To Obtain Warranty Service
If during the Warranty Period, you submit a valid claim to Kedacom or an authorized Kedacom agent, Kedacom will, at its option, (i) repair the Kedacom Product using new or previously used parts that are equivalent to new in performance and reliability, or (ii) exchange the Kedacom Product for a refund of your purchase price. - Page 21 Tel: +86-512-68418188 Fax: 86-512-68412699 Suzhou Keda Technology Co.,Ltd. Singapore: 627A Aljunied Road, #09-07, BizTech Centre, Singapore 389842 Tel: +65-6842-5700 Fax: +65-6842-5900 05.03.800678 V2R1 20181207...
