  • Page 1 Version EFFEKTA POWER SYSTEMS Emergency Power Supply EPS150D – EPS2000D Manual...
  • Page 2 E F F E K T A P O W E R S Y S T E M S Emergency Power Supply EPS150D – EPS2000D  Effekta Power Systems AB Sadelgatan 6 SE-213 77 Malmö, Sweden www.effekta.se Tel +46 40 946020 • Fax +46 40 970070...

  • Page 3: Table Of Contents

    Index Introduction ................1 ............3 System parameters Installation ................4 ............... 4 Mechanical ................5 Charger ..............5 Fuse monitoring ........5 Maintained / Non-maintained output ..............7 24 Volt output ..............7 24 Volt input ..............8 Alarm Outputs ............
  • Page 4 Front Panel ................25 ................25 Display ................26 LEDs ................27 Alarm Specifications ................. 32 ................. 32 Charger ................32 Inverter ..............34 Changeovers Maintanance ................35 ............... 35 1 General ................35 2 Fans ..............36 3 Batteries Layouts of PCB and cabinet ...........

  • Page 5: Introduction

    E P S - D Introduction PS-D stands for Effekta Power Systems Digital and is a series of wall mounted static inverters from Effekta Power Systems AB. These come in 9 different sizes and are designed to supply emergency lighting for at...
  • Page 6 U S E R M A N U A L E P S - D There is also battery circuit monitoring with a deep discharge protection as standard, to maximize battery life. The unit also has a temperature compensation circuit connected to the battery voltage. The monitoring of the system is kept simple with a text display and four color LEDs in the front, to easy measure and diagnose the operation and display possible deviations.

  • Page 7: System Parameters

    U S E R M A N U A L E P S - D System parameters The following are factory settings, visible on the unit’s front display: EPSD: 10/20/30/40/50/600/80/100/140 Software version: LV6-16 Inverter voltage: 230 VAC Soft start inverter: Delayed start-up: Earth leakage monitor: Is auto-testing connected?

  • Page 8: Installation

    U S E R M A N U A L E P S - D Installation Mechanical Units in the sizes EPS150D-EPS900D should be wall-mounted using the mounting angles provided. The bigger units; EPS1200D- EPS2000D are in floor-cabinets but can also be mounted on wall if so is necessary.

  • Page 9: Charger

    U S E R M A N U A L E P S - D Charger The Charger terminals are rated for maximum 2.5 mm² cable. A 3- core cable should be supplied with the earth connected to the terminal rail provided The supply is connected directly to a terminal on the PCB, labeled JP31.
  • Page 10 U S E R M A N U A L E P S - D Technical specifications and data are subject to change without any prior notice.

  • Page 11: Volt Output

    U S E R M A N U A L E P S - D 24 Volt output EPS-Digital has a Volt output placed on terminals JP1 and JP2. This DC output is a low power output, and not designed to power any external loads.

  • Page 12: Alarm Outputs

    U S E R M A N U A L E P S - D Alarm Outputs There are 3 different alarms. The alarms are Common Alarm, Load Fault and Mains Failure. The Common alarm is activated for all alarms that are shown in the display, including Load Fault and Mains Failure.

  • Page 13: First Start-Up Of The Unit

    U S E R M A N U A L E P S - D First start-up of the unit Perform a visual inspection for mechanical damage. Check that the cables have not being damaged against the chassis. Check that all lighting (also other loads) has been power factor corrected to at a minimum cos fi 0.8.

  • Page 14: Settings Routine

    U S E R M A N U A L E P S - D Settings routine The settings routine can only be used when the electronics are switched on from the beginning, achieved by switching the battery off and removing the supply fuse (or remove input supply).
  • Page 15 U S E R M A N U A L E P S - D 5) < OK Weekly Test? Y/N >: select yes or no. This test comprises a weekly test, performed on a set date or day depending on setting, see annual test.
  • Page 16 U S E R M A N U A L E P S - D 19) < Delay? N/Y>: This selection determines whether there should be a pause of 200mS after a power outage before the inverter starts 20) < Earth leakage? N/Y >: select. This selection determines whether the earth leakage monitor should be used 21) <...

  • Page 17: Principal Drawings

    U S E R M A N U A L E P S - D Principal drawings Suggested connections made with the internal 24 Volts power-supply: JP1 pin 1 connected to JP1 pin 2 S U B C - S U B C E N T R A L . A C T I V A T E S A L L O U T P U T S JP2 pin 1 connected to JP1 pin 3 JP1 pin 1 connected to JP1 pin 4...

  • Page 18: Connection Examples

    U S E R M A N U A L E P S - D Connection examples Exempel A-1: Output 1: Always activated. Output 2: Activates when BR1 is closed or at mains failure, tests and 24V inputs. Output 3: Always activated.
  • Page 19 U S E R M A N U A L E P S - D Example A-2: Output 1: Always activated. Output 2: Always activated. Output 3: Deactivated. Activates at mains failure, tests and 24V inputs. Technical specifications and data are subject to change without any prior notice.
  • Page 20 U S E R M A N U A L E P S - D Example B-1 BR-A: For sub-centrals. Closing of the switch activates all the outputs. BR-B: For testing. Closing of the switch activates all the outputs. BR-C: For fire-alarm.
  • Page 21 U S E R M A N U A L E P S - D Example B-3 Testplug: JP1 pin 1 connected to JP1 pin 4 JP2 pin 1 connected to JP1 pin 5 This can be used to activate all of the outputs for maintenance purposes. The outputs will be activated as long as the connections are present and the display will show that an external input is active.

  • Page 22: Operating Modes

    U S E R M A N U A L E P S - D Operating-modes Normal Operation – Under normal operation, the unit will show "System OK" and a "Mains supply on" green light diode will be alight. Once every 90 minutes, the system will check that the battery is connected.

  • Page 23: Mains Power Restored

    U S E R M A N U A L E P S - D Mains power restored – When the mains power exceeds 80% of the nominal value, a green LED diode "Mains ok" is lit, and the red LED diode "Charger Fault"...

  • Page 24: Functions

    U S E R M A N U A L E P S - D Functions Fire-alarm 1 function – if 24VDC is connected to the fire alarm input terminal, the unit will simulate a mains failure, and activate all the outputs on battery mode.

  • Page 25: Autotest - Load Monitoring

    U S E R M A N U A L E P S - D Autotest – Load monitoring – The load monitoring is described by the following procedure. Load monitoring for mixed lighting fitting types. When selected the battery- test and load monitoring will be performed simultaneously.

  • Page 26: Manual Test Function

    U S E R M A N U A L E P S - D Manual test function – During normal operation, both buttons may be pressed simultaneously, bringing up a selection between WEEKLY TEST and ANNUAL TEST. If selecting WEEKLY TEST (left-hand button), a load test will be performed for 20 minutes, indicated by a red LED diode TEST.

  • Page 27: Annual Test

    U S E R M A N U A L E P S - D Annual test – If selected in the Setting Routine, the battery will be tested annually for 60 minutes each time, and will indicate this in the display. The point of departure for the test is that the battery should be fully charged.

  • Page 28: Short Circuit Monitoring

    U S E R M A N U A L E P S - D Short circuit monitoring – This function monitors the 4 output ports individually while using mains power, and the total load while using battery power (15 A / DC per size). If a short circuit occurs while using mains power, the output port fuse shall fail 5 A/FF (breaks at 11 A on.4 sec (2530 VA / W).

  • Page 29: Front Panel

    U S E R M A N U A L E P S - D Front panel Display – The EPS-D is equipped with an easy to use display. The Display has 4 LEDs for status indication and 2 buttons marked A and B. In case of an alarm, the unit will activate a buzzer to alert the user of the situation.

  • Page 30: Leds

    If no successful tests exist, the display will indicate *****************. (automatic scrolling) Fire-alarm 1/2/3 – indicates type of selected fire alarm. Effekta Power Syst. +4640946020 – Shows Company name and number Date/Month/Year/Day – indicates current date. Time – indicates current time, equipped with summer/winter crossover.

  • Page 31: Alarm

    För enklare översikt av larmen och deras innebörd följer en larmlista med orsak och förklaring på följande sida. Skulle fel dyka upp som inte finns med på denna lista så vänligen kontakta Effekta för konsultation. Technical specifications and data are subject to change without any prior notice.
  • Page 32 U S E R M A N U A L E P S - D Alarm Cause Action Load Change: Accept – (alt. +) XXX VA The unit has performed a weekly test. It has discovered that the load differs from the reference load more than the set tolerance value.
  • Page 33 U S E R M A N U A L E P S - D Overload: Accept XXX VA The unit has found that the load it supplies is larger than what it has been designed for. Remove load until it’s within specifications for the unit. If the unit gives of this alarm on with the inverter on idle, notify your retailer.
  • Page 34 U S E R M A N U A L E P S - D Intermittent Earth fault: The unit has discovered a difference between the output current to the load in comparison to the received current from the load in the neutral. If this current exceeds the chosen setting, the unit will shut of the load one output at a time until it has found the cause of the problem.
  • Page 35 U S E R M A N U A L E P S - D Battery Off: Every 90 minutes the unit checks if the batteries are connected. If the alarm is active and the batteries are connected and the battery breaker is on, then the fault might lay with the batteries.

  • Page 36: Specifications

    U S E R M A N U A L E P S - D Specifications Charger Voltage: 230 VAC +-10 % Frequency: 50Hz +-2 % Protection: Mains fuse/Battery fuse/Output fuse/Polarity protection for the battery (Diode), DC Overvoltage & Deep discharge. Battery Charge Current: C/10 A/DC –...
  • Page 37 U S E R M A N U A L E P S - D Short circuit while mains powered: Fuse fail 5 A/FF (breaks at 11 A on.4 sec (2530 VA / W) Short circuit while battery powered: 240% for EPS10D – EPS60D, 210% on EPS80D, 170% on EPS100D, (within 0.4 sec.) or fuse break depending on what comes first.

  • Page 38: Changeovers

    U S E R M A N U A L E P S - D Changeovers Mains to inverter – The inverter starts, synchronized to the mains, between 5 and 20 ms after detection of the mains outage, to ensure a safe load changeover (when load is maintained).

  • Page 39: Maintanance

    (in normal operating conditions) A worn fan can reduce the output power or shorten the units life expectancy. Only fans supplies by Effekta are to be used in EPS-systems. Technical specifications and data are subject to change without any prior notice.

  • Page 40: Batteries

    U S E R M A N U A L E P S - D 3 Batteries The batteries mounted in the EPS-Digital units are classified under Eurobat 1999 "10-12 years - High Performance". The real lifespan is very dependent on operating conditions (number of charging cycles, deep discharge, temperature, etc.).

  • Page 41: Layouts Of Pcb And Cabinet

    U S E R M A N U A L E P S - D Technical specifications and data are subject to change without any prior notice.
  • Page 42 U S E R M A N U A L E P S - D Technical specifications and data are subject to change without any prior notice.

  • Page 43: Fuse-Information

    U S E R M A N U A L E P S - D Technical specifications and data are subject to change without any prior notice.

  • Page 44: Declaration Of Conformity (Ce)

    U S E R M A N U A L E P S - D Technical specifications and data are subject to change without any prior notice.

This manual is also suitable for:
