4 Development and Application

No. Item
Burn
1
Firmware
Testing
2
Board

5 Basic operation

5.1

Hardware design and circuit schematic diagram

Copyright ©2012–2018，Chengdu Ebyte Electronic Technology Co., Ltd
1.The module is embedded with ARM MCU. For program downloading, please use the J-LINK
downloader. Any other serial port or JTAG、ISP、ICP are unavailable to download.
The burn firmware needs to be completed in two parts. Since the protocol stack provided by NORDIC
is not loaded in the program, in the second development, you need to use the official burning tool
nRFgo studio to burn the protocol stack, and then use nRFgo studio to burn. The hex of the application
code; you can also use the official burning tool nRFgo studio to burn the protocol stack, and then
download it with IAR or KEIL.
Testing board is not available.
