2 Specification and parameter

2.1 Limit parameter

Table 2-1 Limit parameter table
Main parameter
Power supply （V）
Blocking power（dBm）
Operating temperature（℃）

2.2 Operating parameter

Table 2-2 Working parameter table
Main parameter
Operating voltage（V）
Communication level （V）
Operating temperature （℃）
Operating frequency（MHz）
Transmitting current （mA）
Receiving current（mA）
Transmitting power（dBm）
Receiving sensitivity
（dBm）
Copyright ©2012–2018，Chengdu Ebyte Electronic Technology Co., Ltd
Performance
Min
0
-
-40
Performance
Min Type
1.7 3.3
- 3.3
-40 -
2360 -
17.5
12.9
8
7.8
8.4
7 7.5
-103dBm @ BLE 125kbps
-96dBm @ BLE 1Mbps
Max
Voltage over 5.5V will cause
5.5
permanent damage to module
Chances of burn is slim when
10
modules are used in short distance
+105 Industrial grade
Max
5.5 ≥3.3 V ensures output power
For 5V TTL, it may be at risk of
-
burning down
85 Industrial grade
2500 Support ISM band
TX only run current
(DC/DC, 3 V) PRF = +8 dBm
TX only run current
(DC/DC, 3 V) PRF = +4 dBm
TX only run current
(DC/DC, 3 V) PRF = +0 dBm
RX only run current (DC/DC, 3
1 Mbps / 1 Mbps BLE
RX only run current (DC/DC, 3
2 Mbps / 2 Mbps BLE
8
long distance mode
E73-2G4M08S1E User Manual
Remark
Remark
V)
V)
