Toggle RS485 AB
Autorun
Firmware version
Port5 Mode
Port6 Mode
OE/OC Mode
SysOk output active
low
Alarm output active low
Warning output
active low
Remote IN
Fieldbus IN (*)
(*): This parameter is only available in (Fieldbus) versions of the Backplane.
ManagerIQEasy_UM_9752103002_GB_V3_1
The signals on the Device communication port
Off
are not switched.
The signals on the Device communication port
On
are switched. Enable this parameter if older
Performax IQ and/or Sensors are used in the
system. The parameter can also be switched on if
a mistake is made during the wiring, as a result of
which Devices are not detected by the HMI.
For a Backplane and Extension IQ Easy, this
Yes
parameter will always be set to Yes. The Backplane
and Extension IQ Easy units will always be started.
Identification of the current firmware version of
the Backplane or Extension IQ Easy.
The Device port is set and suitable for
Serial
communicating with IQ Easy Devices.
The Device port is set to communicate with Non-
Analog I/O
IQ Easy Devices.
The Device port is set and suitable for
Serial
communicating with IQ Easy Devices.
The Device port is set to communicate with Non-
Analog I/O
IQ Easy Devices.
The digital Remote I/O outputs ("All system
OE-Mode
functions OK", "Global Alarm" and "Global
Warning") are used as Open Emitter. See also
Section 5.4.4.1.
The digital Remote I/O outputs ("All system
OC-Mode
functions OK", "Global Alarm" and "Global
Warning") are used as Open Collector. See also
Article 5.4.4.1.
The "All system functions OK" on the Remote I/O
No
output is used as an "Active High" signal. See
also Article 5.4.4.1.
The "All system functions OK" on the Remote I/O
Yes
output is used as an "Active Low" signal. See also
Article 5.4.4.1.
The "Global Alarm" on the Remote I/O output is
No
used as "Active High" signal. See also Article
5.4.4.1.
The "Global Alarm" on the Remote I/O output is
Yes
used as "Active Low" signal. See also Article
5.4.4.1.
The "Global Warning" on the Remote I/O output
No
is used as "Active High" signal. See also Article
5.4.4.1.
The "Global Warning" on the Remote I/O output
Yes
is used as "Active Low" signal. See also Article
5.4.4.1.
Feedback from the "Remote On/Off" signal from
Off
the Remote I/O connector. Can be used for
On
testing purposes. See also Article 5.4.4.2.
Feedback from the "Remote On/Off" control of
Off
the Fieldbus protocol. Can be used for testing
On
purposes.
