CAR MULTIMEDIA SYSTEM
USER'S MANUAL
ACCENT
Thank you for purchasing this multimedia system.
Before using the product, read the contents of this user's manual carefully and use this product safely.
ENGLISH
TIẾNG VIỆT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Accent and is the answer not in the manual?

Questions and answers

Related Manuals for Hyundai Accent

Summary of Contents for Hyundai Accent

  • Page 1 ENGLISH TIẾNG VIỆT CAR MULTIMEDIA SYSTEM USER’S MANUAL ACCENT Thank you for purchasing this multimedia system. Before using the product, read the contents of this user's manual carefully and use this product safely.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Basic Bluetooth Audio ......23 Safety Warnings ....... 3 Safety Cautions .

  • Page 3: Basic

    BASIC • Please refrain from use if the screen is Safety Warnings blank or no sound can be heard as these signs may indicate product malfunction. • Even when receiving route guidance from Continued use in such conditions could the Navigation system, please abide by lead to accidents (fires, electric shock) or actual traffic and road regulations.

  • Page 4: Safety Cautions

    BASIC • Do not subject the device to severe shock • The design and specification of this product Safety Cautions or impact. Direct pressure onto the front may change without prior notification for side of the monitor may cause damage to product improvement.

  • Page 5: Component Names And Functions

    COMPONENT NAMES AND FUNCTIONS ➏ MEDIA ➊ POWER/VOL ➋ RADIO ➐ PHONE ➌ ➑ SETUP ➒ TUNE ∧SEEK/TRACK∨ ➍ MAP ➎ DISP ➋ ➍ ➎ ➌ ➊ ➒ ➏ ➐ ➑ · FM/AM mode : plays previous/next frequency ➊ POWER/VOL ➍...
  • Page 6 ➐ PHONE Displays the Phone mode. ➑ SETUP Displays the Setup mode. ➒ TUNE FM/AM mode: changes the frequency.

  • Page 7: Steering Wheel Control

    STEERING WHEEL CONTROL ➋ ➊ ➌ ➍ ➎ ➏ ➐ ➊ Voice Recognition ➍ ➏ MUTE Activates voice recognition(it is only Mutes sound. · When pressed in the incoming call screen, available when connected to the Apple answers the call. ➎...

  • Page 8: Home / All Menus

    HOME / ALL MENUS ➍ Image Home Screen All Menus Displays the Image mode. Controls Menu Configuration for the Home ➎ iPod Screen Converts to iPod mode. ➏ AUX Converts to AUX mode. ➐ Bluetooth Audio Converts to Bluetooth Audio mode. ➊...

  • Page 9: Radio

    RADIO ➍ Frequency Bar FM/AM · Flick the frequency bar left/right to search for available radio channels to the left or right of You can access the radio either by pressing the current channel. the FM/AM hard key. · Dragging: Drag the frequency bar to the left/ right to find the radio channel that you want.

  • Page 10: Bluetooth

    BLUETOOTH What is Bluetooth Wireless CAUTIONS upon Connecting Precautions for Safe Driving Technology? Bluetooth Phone • Bluetooth Wireless Technology refers to a • Bluetooth Handsfree is a feature that • Before connecting the head unit with the short-distance wireless networking technol- enables drivers to practice safe driving.
  • Page 11 BLUETOOTH • Bluetooth connection may become intermit- tently disconnected in some mobile phones. Follow these steps to try again. ➊Turn the Bluetooth function within the mobile phone OFF/ON and try again. ➋Turn the mobile phone power OFF/ON and try again. ➌Completely remove the mobile phone bat- tery, reboot, and then again.

  • Page 12: Bluetooth Connection

    BLUETOOTH Bluetooth Connection ➌ ※ Up to 5 Bluetooth devices can be paired. Call ※ Makes a call after you dial a number and Only one Bluetooth device can be con- select Call. nected at a time. ➍ Phone Settings Before you can use the Bluetooth feature, you ※...
  • Page 13 Delete the numbers that you entered. If there is an incoming call after you made a Bluetooth connection, a incoming call screen will appear. ➊ Accept Answers the call. ➋ Reject Ignores the call. ※ In some mobile phones, the caller's number may not be displayed, and the Ignore feature...
  • Page 14 BLUETOOTH ➌ Received Using the Menu During a Phone Call ※ If the caller's number is listed in Contacts, When making a call, you can use the following Lists the calls that you have received. the caller's name will be displayed. menu items.

  • Page 15: Phone Settings

    BLUETOOTH ➊ Bluetooth Connection Contacts ※ Some devices require a device authenti- Settings for deleting and disconnection of a cation for downloading your contacts. If Bluetooth device. download fails, check your phone screen and confirm the download if necessary. ➋ Disconnect ※...

  • Page 16: Media Music

    MEDIA ➎ Repeat Music Repeats the current file. ➏ Shuffle Plays files in random order. ➐ List Moves to the list screen. ➑ Sound settings ➓ Upper Folder Moves the Sound settings screen. Moves to upper folder. ➒ Back Button ➊...

  • Page 17: Video

    MEDIA ➏ List Video Back Button Moves to previous screen. Moves to the list screen. ➐ Sound settings ※ The touch screen may not work for some Moves the Sound settings screen. functions when the vehicle is in motion. The touch screen feature will be supported ➑...

  • Page 18: Image

    MEDIA ➏ Adjust Image Size Image Enlarge/reduce (zoom-in/zoom-out) image size. ➐ List Moves to the list screen. ➑ Back Button Moves to previous screen. ➊ Image Displays current operating mode. ➋ Previous/Next File Swipe image left or right to see Previous/Next image.

  • Page 19: About Usb

    MEDIA • Repeated connecting/disconnecting of USB • The device may not operate normally if MP3 About USB devices within short periods of time may Players, cellular phones, digital cameras, or result in product malfunction. other electronic devices (USB devices not •...

  • Page 20: Supported Specifications

    MEDIA • USB memory files cannot exceed 4GB per Supported Specifications file. • USB memories will stably recognize up to 32GB. Name Description • Saving too many files may influence system performance and result in reduced recogni- Image format JPG, PNG tion speeds.

  • Page 21: Ipod

    MEDIA ➏ Shuffle iPod Plays files in random order. ➐ List Moves to the list screen. ➑ Sound settings Moves to the Sound settings screen. ➒ Back Button Moves to previous screen. ➊ iPod Displays current operating mode. ➋ Previous File Moves to the previous file or play the current file from the beginning (Depends on the play time).

  • Page 22: Using Ipod Devices

    MEDIA • For some iPod Touch and iPhone devices, Using iPod Devices connected to the vehicle while it is playing, connecting Bluetooth while the iPod is a high pitch tone may sound for about 1~2 operating may result in discontinued iPod seconds immediately after connection.
  • Page 23 MEDIA • If connect to the Multimedia system while device. Reset the device or delete the same songs in the Apple device using iTunes. podcast or iTunes music downloading to iPod/iPhone, it may occur some problems • If the iPhone/iPod Touch supports when you select song in the list.

  • Page 24: Aux

    MEDIA ※ If only a cable is connected to the AUX without an external device, the mode will be changed to AUX, but noise may occur. Connecting an External Device When an external device is not being used, If an external device connector is connected remove the connector jack.

  • Page 25: Bluetooth Audio

    MEDIA ➎ Sound settings Bluetooth Audio Moves to the Sound settings screen. ➏ Back Button Moves to previous screen. ※ Artist info and Title may not be supported by mobile phone. ※ If the music in the mobile phone is not played after changing to audio streaming mode, press the play button.

  • Page 26: Apple Carplay

    Apple CarPlay What is Apple CarPlay? Precautions due to mobile phone issues. • Carrier charges may apply when using Apple CarPlay. • Apple CarPlay is a registered trademark of • The following problems may occur due to You can securely access your smartphone while driving by using this feature.

  • Page 27: Using Apple Carplay Features

    Apple CarPlay Using Apple CarPlay Cautions when using Features Apple CarPlay • Please refer to the following site for features 1. Connect the mobile device to the USB port using a USB cable. (Use genuine USB and country availability about Apple CarPlay cable.) and Siri / Maps, etc.

  • Page 28: Setup

    SETUP ➊ Fader & Balance Setup Display Settings Select the Up/Down/Left/Right button to con- trol sound positioning. Setup is the screen to control system settings You can directly touch or drag the sound of the multimedia system. position to make adjustments. To enter the screen, select the SETUP key of Press Center to concentrate the sound on the the device.

  • Page 29: Clock Settings

    SETUP Clock Settings Language Settings Frame Settings Provides the time and date settings. You can configure the displayed system lan- guage. You can select any of the following screen Provides the GPS time, Date/Time Settings formats to be displayed when the screen or and 24 Hours options.

  • Page 30: System Info

    SETUP System Info At the System Info screen, System version information details are available.

  • Page 31: Rear View Camera

    REAR VIEW CAMERA Rear View Camera This parking guide system is activated if you shift the gear to R when the power is on or the engine has started. A wide-angle lens is installed as the rear detection camera to get a wider view, so there may be some difference between the actual distance and the distance that appears on-screen.

  • Page 32: Product Specification

    PRODUCT SPECIFICATION Radio Channels FM : 87.5 MHz ~ 108.0 MHz(Step : 100 kHz) AM : 531 kHz ~ 1602 kHz(Step : 9 kHz) Sensitivity FM : Under 10dBu/AM : Under 35dBu FM Stereo Separation More than 20dB Recommended Sampling rate 44.1 KHz, Bit Rates and Bit rate: 32-320 KB/s with VBR Sampling Frequency...

  • Page 33: Troubleshooting

    TROUBLESHOOTING 1. Errors which occur during the operation or installation of the device may be mistaken as a malfunction of the actual device. 2. If you are having problems with the device, try the suggestions listed below. 3. If the problems persist, contact service center. Problem Possible Cause •...
  • Page 34 TROUBLESHOOTING Problem Possible Cause Countermeasure • Check to see that the device has been properly connected. The power does not turn on Device is not properly connected • Charge the battery If the problem persists, contact your The system does not play The vehicle battery is low point of purchase or service center.
  • Page 35 FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
