Hyundai ACCENT Quick Reference Manual

WALK THE CUSTOMER THROUGH EACH OF
THE FOLLOWING KEY DELIVERY FEATURES
☐
HOW TO DEFROST - page 16
Press the front defrost button
1
Set to the warmest temperature setting
2
Set to the highest fan speed
3
☐
TIRE PRESSURE MONITORING SYSTEM (TPMS) - page 29
LOW TIRE PRESSURE INDICATOR /
TPMS MALFUNCTION INDICATOR
NOTE: Tire pressure may vary in colder temperatures causing
the low tire pressure indicator to illuminate. Inflate tires
according to the Tire Pressure Label located on the driver's side
door pillar.
☐
WINDSHIELD WIPER / WASHER - page 11
• To activate wipers, move the lever
MIST
down to one of the three positions
OFF
(INT, LO, HI)
INT
• To adjust "INT" speed, move the switch.
LO
• To spray the washer fluid, pull the
HI
lever towards you
• Push the lever up for a single wiper
pass
☐
UNLOCKING VEHICLE - page 02
LOCK
UNLOCK
TRUNK OPEN
ALARM
MAINTENANCE
Scheduled Maintenance Normal Usage
Engine Oil and Filter Replace 7,500 or 12 mos.
Fuel Additives *1 Add 7,500 or 12 mos.
Tire Rotation Perform 7,500
Inspect 7,500
Air Cleaner Filter
Replace 22,500
Vacuum Hose Inspect 7,500
Climate Control Air Filter
Replace 7,500 or 12 mos.
(for Evaporator and Blower Unit)
Air Conditioning Refrigerant Inspect 7,500
Brake Hoses & Lines Inspect 7,500
Drive Shafts & Boots Inspect 7,500
Exhaust Pipe & Muffler Inspect 7,500
Front Brake Disc/Pads, Calipers Inspect 7,500
Rear Brake Drum / Linings
Inspect 7,500
Rear Brake Disc / Pads
Steering Gear Box, Linkage & Boots /
Inspect 7,500
Lower Arm Ball Joint, Upper Arm Ball Joint
Suspension Mounting Bolts Inspect 7,500
Brake / Clutch Fluid Inspect 15,000
Crankcase Ventilation Hose Inspect 15,000
Fuel Filter Inspect 15,000
Fuel Lines, Fuel Hoses and Connections Inspect 30,000
Fuel Tank Air Filter Inspect 15,000
Parking Brake Inspect 15,000
Vapor Hose, Fuel Tank & Fuel Filler Cap Inspect 15,000
Spark Plugs Replace 97,500
1st Inspect 60,000 or 72 mos.
Drive Belt (Alt, A / C)
Add'l Inspect 15,000 or 24 mos.
1st Inspect 120,000 or 120 mos.
Coolant
Add'l Replace 30,000 or 24 mos.
Manual Transmission Fluid Inspect 30,000
Automatic Transmission Fluid No checks, No services required
*Check the engine oil regularly between recommended oil change. Hyundai recommends Quaker State oil.
*1 If TOP TIER Detergent Gasoline is not available, one bottle of additive is recommended. Additives are available
from your authorized Hyundai dearler along with information on how to use them. Do not mix other additives.
*See Owner's Manual for details regarding Severe Usage maintenance recommendations.
Looking For more detailed information? This Quick Reference Guide does not replace your vehicle's
Owner's Manual. If you require additional information or are unsure of a specific issue,We
recommend that you always refer to the vehicle's Owner's Manual or contact your authorized
Hyundai dealer. The information contained in this Quick Reference Guide is correct at the time
of printing; however, specifications and equipment can change without notice. No warranty or
guarantee is being extended in this Quick Reference Guide, and Hyundai reserves the right to
change product specifications and equipment at any time without incurring obligations.
Some vehicles are shown with optional equipment.
Severe Usage*
Replace 3,750 or 6 mos.
HYUNDAI
Add Same as Normal
Perform 7,500
Inspect Same as Normal
Replace More Frequently
ACCENT
Inspect Same as Normal
Replace More Frequently
Inspect Same as Normal
Inspect Same as Normal
Inspect 3,750 or 6 mos. Quick Reference Guide
Inspect Same as Normal
Inspect More Frequently
Inspect More Frequently
Inspect More Frequently
Inspect Same as Normal
Inspect Same as Normal
Inspect Same as Normal
Inspect Same as Normal
Inspect Same as Normal
Inspect Same as Normal
Replace More Frequently
Inspect Same as Normal
Replace More Frequently
Inspect Same as Normal
Replace Same as Normal
Replace 75,000
Replace 60,000
Roadside Assistance:
Consumer Affairs:
XM ® Radio:
Sirius
NP150-Q2018-A
(Rev 09/23/17)
Blue Link:
Printing 09/27/17
1-800-243-7766
1-800-633-5151
1-800-967-2346
1-855-2BLUELINK
(1-855-225-8354)
