- Page 26 73.00 127.0 cm 57.75 111.2 cm 146.7 cm 111.2 cm 43.75 111.2 cm 81.00 77.50 196.9 cm 205.7 cm MACHINE FRONT FOUNDATION LINE 201.50 511.8 cm Note: Foundation must extend at least 1ft. from bored holes. Machines with outriggers must have the foundation extend at least 1 ft.
- Page 29 52.00 (132.1 cm) 98.50 (250.2 cm) 60.00 INCHES MINIMUM, FIRST HOLE (142.4 cm) 4.95 (12.5 cm) 72.50 (184.5 cm) 257.00 (652.8 cm) 40.20 (102.0 cm) 72.80 (185.0 cm) COOLANT TANK...
- Page 30 73.00 127.0 cm 57.75 146.7 cm 111.2 cm 111.2 cm 42.00 106.7 cm 94.00 238.8 cm MACHINE 81.00 50.00 FRONT 205.7 cm 127.0 cm OUTRIGGER FOOT 24.00 61.0 cm FOUNDATION LINE 201.50 511.8 cm Note: Foundation must extend at least 1ft. from bored holes. Machines with outriggers must have the foundation extend at least 1 ft.
- Page 33 52.00 MIN. (132.0 cm) 60.00 MIN. (152.4 cm) DOOR 98.60 SWING (250.0 cm) 37.35 5.04 (64.9 cm) (12.8 cm) 159.60 (405.4 cm) BASE CASTING FRONT 257.00 (652.8 cm) 40.20 (102.0 cm) 72.80 (185.0 cm) COOLANT TANK...
- Page 418 • • • • • •...
- Page 436 & / 0F TOOL HOLDER TOOL CHANGER COVER 9" (22.86 cm) MAX Z-AXIS TOOL TRAVEL OF TOOL HOLDER V-GROOVE CHANGE LOWEST POINT ON CAROUSEL POSITION APC DOOR 25" OPENING 21" (63.5 cm) (53.34 cm) 19.9 20“ 116" (294.64 cm) ENCLOSURE USEABLE WORK SPACE MILL TABLE (AT HOME POSITION) SIZE: VF-3 48"...
- Page 492 45 37 36 45 28 24 44 27 31...
- Page 494 BOTTOM DESIGNATES PARTS AVAILABLE FROM HAAS SERVICE DEPT.
- Page 503 40-16095 SHCS, 10-32 x 1/4" 40-1697 SHCS, 1/4-20 x 3/4" 40-1704 FHCS, 10-32 x 1/4" 45-0045 WASHER, BLK HARD 1/4" x 1/8" THK. 48-0004 SPRING PIN, 3/8" x 1" DESIGNATES PARTS AVAILABLE FROM HAAS SERVICE DEPT. * DESIGNATES REMOVED PART...
- Page 511 ITEM PART DESCRIPTION ITEM PART DESCRIPTION 45-1682 WASHER,SPLIT LOCK 7/16MED 20-0064 ADAPTER ENCODER PULLEY 45-1700 WASHER, INTERNAL LOCK #8 20-7011D HOUSING GEARBOX MACHINING 45-1740 WASHER, BLACK HARD 1/2 20-7062 BRG FORK, GEAR CLUSTER 45-1851 WASHER TRANS 20-7064 TRANSFER SHAFT 46-1617 NUT, HEX 8-32 20-7374 1 1/8 SPROCKET...
- Page 516 SNAP RING N5000-131 20-7532 LOCK 50MM ANG CNTACT BRNG 57-2984 O-RING 2-158 VITON 24-4200 BRONZE FILTER ELEMENT 57-2990 O-RING 2-348 BUNA 30-3415F DRAWBAR ASSY HC TSCHP CARB 58-1627 1/8-27 PIPE PLUG DESIGNATES PARTS AVAILABLE FROM HAAS SERVICE DEPT. * DESIGNATES REMOVED PART...
-
Page 519: Service Department
30-3292 TOOL RELEASE PISTON ASSEMBLY ITEM PART NO. DESCRIPTION 20-7007A CYLINDER HOUSING MACHINED 20-7043A PISTON TRP RECTANGLE 20-7044C SHAFT TRP 22-7045A SPRING RETAINER TRP 30DEG 25-7050B SWITCH MNT., TOOL RELEASE 29-7397 LABEL, TOOL RELEASE PISTN 32-2010 24 LIMIT SWITCH 32-5620 TRP SOLENOID VALVE ASSY 40-1632 SHCS 1/4-20 X 1/2... - Page 525 COUPLING ASSY "B" SEE TABLE BALLSCREW "A" SEE TABLE ITEM PART NO. TITLE 20-0151 MOTOR MOUNT 40/50mm BS MACH. 20-9213 SPACER RING 40mm BALL SCREW 30-0472 SUPPORT BEARING ASSY 30-1222 BALL SCREW SUPPORT BEARING ASSY 51-0008 BEARING LOCKNUT TCN-06-F 20-0142 SNAP LOCK RING BMPR 20-0146 SNAP LOCK RING BMPR...
- Page 529 ITEM QTY PART No. TITLE 20-7403 COUPLING, SERVO DRIVE 20-7615 COUPLER, BRUSHLESS 51-2014 BEARING LOCKNUT, CL18F 56-0065 SNAP RING, (5100-112) 59-2060 FLEXPAK FOR AJ05 WHERE USED APPLICATION SL20 30-0615 BS ASSY 32mm(1.26) x 33.27 SL30 30-0617 BS ASSY 32mm(1.26) x 48.23 BS ASSY 32mm(1.26) x 25.65 SL40 30-0451...
