SPECIFICATIONS

Note : Specification and others are subject to change without notice for improvement.
Video input system:
O
PAL-B/G, D/K, I/I
SECAM-B/G, D/K
NTSC 4.43(AV)
Intermediate Frequency (Unit : MHz)
O
VISION IF : 38.9MHz
COLOR IF : 34.47MHz(4.43)
35.32MHz(3.58)
VIF-4.25000MHz
(
VIF-4.40625MHz
Tuning range
O
Band
VHF-Low
VHF-High
Hyper
UHF
Tuning system :
O
FVS
100 Programme memory
Antenna input impedance : VHF/UHF 75 ohm, unbalanced
O
OSD (On Screen Display) : WINDOW 3D Type
O
Voice coil impedance : 8 ohm
O
Sound output : 10W+10W(Max 12W+12W)
O
Dual/Stereo : AV Stereo
External connection :
O
External In/Output
O
Audio-In:0.5Vrms±3db,over 10Kohm
Audio-Out:0.5Vrms±3db,below 1Kohm
Video-In/Out:1Vp-p±3db,75ohm
: NTSC-M
): SECAM
For TV
B/G
D/K
Ch2-4
Ch1-5
Ch5-12
Ch6-12
Ch21-69
Head Phone Jack
Front or
Side
A/V in :1 pair
A/V in/out
Back
SOUND IF :
Power requirement : 110~240V, 50/60Hz
O
Power consumption : 95W
O
CPT : True Flat CPT(Flatron)
O
For CATV
I/I
S1'-S3', S1
S2-S10,
Ch4-13
S11-S20
S21-S41
Feature :
O
- 4 -
33.4MHz (B/G)
32.9MHz (I/I)
32.4MHz (D/K)
Auto programme/Manual programme
Digital Eye
Digital Comb Filter
Auto Sleep
Dynamic Focus(Option)
Programme Editing
PSM (Picture Status Memory)
CTI
Turbo Search, Picture & Sound
ACMS
ARC (Zoom 1, 16:9↔4:3)
2 TUNER PIP(Double Window PIP)-Option
