OptiFlow IG06-BN – spare parts list
OptiFlow IG06-BN Powder injector – complete (pos. 1-13)
Conveying air check valve unit (red marking) – complete (incl. pos. 6, 8, 9 and
A
12)
Supplementary air check valve unit (black marking) – complete (incl. pos. 7, 8, 9
B
and 13)
Injector body – complete (incl. pos. 1, 2, 10 and 11)
C
1 Injector body (without pos. 2)
O-ring – Ø 16x2 mm
2
Insert sleeve – PTFE, complete
3
Hose connection – Ø 10-12 mm, complete (incl. pos 4.1)
4
O-ring – Ø 16x1.5 mm
4.1
5 Threaded sleeve
Connector (conveying air) – NW 5.5
6
Connector (supplementary air) – NW 5.5
7
O-ring – Ø 11x1.5 mm
8
Filter element – Ø 9/4x27 mm
9
Nozzle – Ø 2.2 mm
10
Nozzle fixation – complete (incl. pos. 11.1)
11
O-ring – Ø 8x1 mm
11.1
12 Body (red)
13 Body (black)
Conveying air hose – Ø 8/6 mm (red)
16
Supplementary air hose – Ø 8/6 mm (black)
17
Quick release coupling for conveying air hose – NW5-Ø 8 mm
18
Quick release coupling for supplementary air hose – NW5-Ø 8 mm
19
20 Kink protection
Powder hose – PUR, Ø 12.5/9.5 mm
22  Spare parts list
Rev. 00 05/19
* Please indicate length
# Wearing part
1015 810
1005 589
1005 590
1015 812
1006 484
1007 794#
1006 485#
1006 531
205 141#
1006 483
1004 366
1004 367
1000 532#
1003 698
1015 813
1007 792
1007 793#
1004 369
1004 370
103 500*
1008 038*
261 645
261 637
1008 844
103 705*#
OptiFlow IG06-BN
