Maintenance / Repairs

Reinigung

Cleaning

Cleaning the injector

OptiFlow IG06-BN
Rev. 00 05/19
ATTENTION
Any unauthorized modifications and alterations to the product are
not permitted for safety reasons and exclude the manufacturer's
liability for any resulting damage!
Regular and conscientious cleaning and maintenance increase
the service life of the product and ensure consistent high coating
quality!
–
The parts to be replaced during maintenance work are available
as spare parts. These parts can be found in the appropriate
spare parts list!
1. Remove the injector
2. Remove the powder hose from the hose connection (2)
3. Clean the hose connection (2) with compressed air which is free of
oil and water, and check for wear
4. Clean the injector body (4) with compressed air which is free of oil
and water.
–
Any contamination can be seen through the opening of the
hopper fitting (3)
5. If the injector is severely fouled, it must be dismantled
ATTENTION
Injector parts may be damaged during the cleaning process.
► Remove the check valve units (1 and 6) with the correct sized
spanner.
► Clean the component parts with compressed air and, if
necessary, dissolve sintered deposits with nitro-thinner.
► Do not use acetone, do not scrape!
6. Reinsert the injector and fix it
