Apogee Loudspeaker AE-7 Product Dimensions

12.258 [311.35]
15?
25.031
[635.79]
A
24.064 [611.23]
38.000
[965.20]
A

FRONT VIEW

W/GRILL REMOVED
NOTE: DIMENSIONS ARE IN INCHES & [MILLIMETERS]
3.577 [90.86]
16.656
[423.06]
2.625 [66.68]
36.500
[927.10]
.750 [19.05]

SECTION A-A

AE-7 LOUDSPEAKER

ACCESS DOORS

CONNECTOR PANEL

NOT TO SCALE
INFORMATION CONTAINED
IN THIS DOCUMENT IS
THE SOLE PROPERTY
SCALE DRAWN
OF APOGEE SOUND 1/5
WWE 9/30/99
INTERNATIONAL, LLC.
REPRODUCTION OF ALL REVISED
OR ANY PART OF THIS PRODUCT
DOCUMENT WITHOUT
NUMBER: SIZE DRAWING N0.
WRITTEN CONSENT
D
FROM APOGEE ZAE-7
SOUND INTERNATIONAL, 100-7700
LLC. IS PROHIBITED.
R
AE-7 LOUDSPEAKER
SERIAL NO. 0 0 0 0 0 0 ------
MADE IN USA
15.250
[387.35]
TM
REVISION
AE-7 LOUDSPEAKER
A
