Apogee Floor Monitor FS-2 Product Dimensions

11.250 [285.75]
.625 [15.88]
18.000
[457.20]
13.750
[349.26]

FRONT VIEW

W/GRILL REMOVED
NOTE: DIMENSIONS ARE IN INCHES & [MILLIMETERS]
22.750 [577.85]
21.500 [546.10]
A
R
A

FS-2 FLOOR MONITOR

R2.500 [R63.50]
13.444
[341.46]
60?
SECTION A-A

CONNECTORS

NOT TO SCALE
INFORMATION CONTAINED
IN THIS DOCUMENT IS
THE SOLE PROPERTY
SCALE DRAWN
OF APOGEE SOUND 1/3
INTERNATIONAL, LLC.
REPRODUCTION OF ALL REVISED
OR ANY PART OF THIS PRODUCT
DOCUMENT WITHOUT
NUMBER: SIZE
WRITTEN CONSENT
D
FROM APOGEE
SOUND INTERNATIONAL, 101-0200
LLC. IS PROHIBITED.
19.383 [492.34]
HANDLE
(THIS SIDE ONLY)
TM
WWE 9/15/99
DRAWING N0. REVISION
FS-2 MONITOR
A
ZFS-2
