Apogee Loudspeaker AE-5 Product Dimensions

OVERHEAD VIEW

2.375 [60.33]
10.625
[269.88]
13.500
[342.90]
16.500
[419.10]
A
14.125 [358.78]
23.031
[584.99]
A

FRONT VIEW

W/GRILL REMOVED
NOTE: DIMENSIONS ARE IN INCHES & [MILLIMETERS]
AE-5 LOUDSPEAKER
10?

NUTPLATE

(TOTAL OF FOUR)
21.781
[553.24]
.625 [15.88]

SECTION A-A

BOTTOM VIEW

STAND FITTING

CONNECTOR PANEL

NOT TO SCALE
INFORMATION CONTAINED
IN THIS DOCUMENT IS
THE SOLE PROPERTY
OF APOGEE SOUND SCALE 1/4 DRAWN
WWE 8/26/99
INTERNATIONAL, LLC.
REPRODUCTION OF ALL REVISED
OR ANY PART OF THIS
PRODUCT
DOCUMENT WITHOUT
NUMBER: SIZE DRAWING N0.
WRITTEN CONSENT
D
FROM APOGEE
ZAE-5
SOUND INTERNATIONAL, 100-5010
LLC. IS PROHIBITED.
R
AE-5 LOUDSPEAKER
SERIAL NO. 0 0 0 0 0 0 ------
MADE IN USA

REAR VIEW

TM
REVISION
A AE-5 LOUDSPEAKER
