C
ONTROLLING THE DEVICE VIA
The device can be controlled directly via port 10001. After the console has been opened, a click on ‚Start' and ‚Ausfüh-
ren' opens an input field. After the commands
telnet xxx.xxx.xxx.xxx 10001.
Alternatively, many terminal programs offer the possibility to establish a TCP/IP or telnet connection.
T
ELNET CONNECTION WITH
Realterm is a free OpenSource terminal program, which may be downloaded here: http://realterm.sourceforge.net/
After the program was installed and executed, the box
The IP address must be entered within the tab
button Open must be clicked. In the terminal box the desired commands can be sent to the device.
For more Information please look at:
http://www.et-system.de/en/produkte/applications-special-units.html
ET System electronic GmbH
T
ELNET
cmd
When controlling the device via port 10001, the user interface
of the device must not be open in a browser!
R
EALTERM
Port
command
or have been entered, a DOS window opens with:
Half Duplex must be checked within the tab Display.
in the following format: xxx.xxx.xxx.xxx:10001. Afterwards the
Ext. Control: Ethernet (LAN) (OPTION)
27
