Summary of Contents for WattBox WB-250-IPW-2
- Page 1 FCC ID: 2AJAC-WB250 IC: 3616C-WB250 ™ WB-250-IPW-2 QUICK START GUIDE...
- Page 2 ANATOMY WB-250-IPW-2 POWER...
- Page 3 A. Outlet LEDs: These illuminate when power to the matching outlet is on. The outlets are switchable (IP controlled). B. Power/Network LED: See page 4. C. AC Power Button: Press to manually toggle the outlets on or off. D. Mounting Eyelets. E.
-
Page 4: Led Indicators
Off: No AC power. Solid Green: Outlets ON. Outlet Off: Outlets OFF. LEDs Note: Each outlets is controllable. PACKAGE CONTENTS This package contains: • The WattBox 250 Series Power Strip • Removable IEC power cord • 2 wall anchors with M3×16mm screws... -
Page 5: Mounting Instructions
(not provided) to attach the unit to a flat surface. An optional mounting bracket is available as a separate accessory. CONNECTION DIAGRAM OvrC Web Server Internet Mobile Apps Web Browser Access Use OvrC Web and smartphone apps to monitor the WattBox remotely WB-250-IPW-2 Router NETWORK RESET... -
Page 6: Installation
INSTALLATION NOTE: This device always connects via the wired connection while it is physically connected to an active network switch port. The Wi-Fi capabilities are only activated when the device is not hardwired to a network. 1. Ensure the WB-250 is connected by ethernet cable to the internet. 2. -
Page 7: Troubleshooting
TROUBLESHOOTING Symptom Possible Cause Remedy A device won’t The WB outlet is Log in to the WattBox interface to turn power up when switched off. the outlet on. the WattBox is The device is not Turn the device’s power switch on. -
Page 8: Important Safety Instructions
WARNING – Liquid: Avoiding Electrical Shocks Do not operate the WattBox if liquid of any kind is spilled onto or inside the unit. Do not operate it near rain or water, even water that is contained (e.g., bathtub or sink). - Page 9 WARNING – No User Serviceable Parts Inside If the WattBox is not operating properly, do not remove any part of the unit (cover, etc.) for repair. Unplug the unit and consult the warranty section of the owner’s manual.
-
Page 10: Industry Canada Statement
• Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the re-ceiver is connected. • Consult the dealer or an experienced radio/TV technician for help. 15.21 Any changes or modifications not expressly approved by the party responsible for compliance could void the authority to operate equipment. -
Page 11: Warranty
WARRANTY 2-Year Limited Warranty This SnapAV® product has a 2-Year Limited Product Warranty. This warranty includes parts and labor repairs on all components found to be defective in material or workmanship under normal conditions of use. This warranty shall not apply to products which have been abused, modified, or disassembled. - Page 12 LOGGING IN TO THE WEB INTERFACE You need to enter the username and password to access the web interface. The default entries are below; change these to maintain proper security (and log them below). Username default: wattbox New Username: Password default: wattbox...
Need help?
Do you have a question about the WB-250-IPW-2 and is the answer not in the manual?
Questions and answers
Hello. I have a new WB-250-IPW-2. I plug in the power and network cable. I get blinking amber no matter what I do. I don't see any light on the network port, neither on my switch. I reset it and still nothing. Keeps blinking amber.
