- Page 1 Smart IoT Gateway - iConnector USER GUIDE FOR ICONNECTOR 3G INTEGRATED WIRELESS CO-ORDINATOR STHC-ISG02DB-WS433-CL-04 USER GUIDE FOR ICONNECTOR 3G STHC-B-ISG02DB-03...
-
Page 2: Specification
USER GUIDE FOR ICONNECTOR 3G INTEGRATED WIRELESS CO- ORDINATOR STHC-ISG02DB- WS433-CL-04 STHC-ISG02DB-WS433-CL-04-MN-EN-01 FEB-2020 This document is applied for the following products STHC-ISG02DB HW Ver. FW Ver. WS433-CL-04 HW Ver. FW Ver. 1.9.3 iConnector 3G Dual Band*, internal GSM antenna, integrated wireless co-... -
Page 3: Product Pictures
RF frequency band datasheets) ETSI EN 300 220, EN 303 204 (Europe) FCC CFR47 Part15 (US), ARIB STD- Ready to comply T108 (Japan)** Vietnam Type Approval Certification QCVN 73:2013/BTTTT, QCVN 96:2015/BTTTT (DAVITEQ B00122019) Security Standard AES-128 Operating temperature -40oC..+85oC SIM slot... - Page 4 or the buzzer buzzes 3 Beep => release the push button or take the magnet to perform the User factory reset (User factory reset = reset frequency number, RF transmit power, data rate, Node ID of 40 WS, Modbus operating parameters, compare time for data status) If it takes more than 30 seconds, the button will be deactivated 5.1 Add Sensor Node...
-
Page 5: Sim Configuration
First, you need to prepare STHC-ISG02DB-WS433-CL-04-H9.png Step 1: Open Modbus tool on PC You can download Daviteq Modbus Configuration Tool Version 1.2 with the following link: http://filerun.daviteq.com/wl/?id=RtuE0i9N8KNJ8fTVdHv4DcJEHdaDcetp Unzip TOOLS-SW-EN-02.zip and run file application "Daviteq Modbus Configuration Tool Version" Choose COM Port (the Port which is USB cable plugged in) Set the BaudRate: 9600, Parity: none Click “... -
Page 6: Mounting Bracket Installation
5.4 Reset sensor and iConnector sensor node Step 1: Connect Antenna, RS485 - configuration cable and power supply co-ordinator Step 2: Put the magnet closer to the icon on iConnector until you hear "peep" 3 times to reset (2 times for 625 kps option) Step 3: Take off the sensor cover and press the button until you see LED flashes 3 times to reset (2 times for 625 kps option) -
Page 7: Troubleshooting
7. Troubleshooting Phenomena Reason Solutions No power supply, the power Check the power connection cord is incorrectly connected Check the connection modbus A, Modbus connection pin A, B is loose or wrong Check the configuration of slave Configuration slave address, address, baudrate, parity Cannot read modbus baudrate, parity is not... - Page 8 Mobile : +012-376 7181 Fax : +603-4143 3388 Manufacturer logo.jpg Dai Viet Controls & Instrumentation Company Ltd. No.11 Street 2G, Nam Hung Vuong Res., An Lac Ward, Binh Tan Dist., Ho Chi Minh City, Vietnam. Tel: +84-28-6268.2523/4 (ext.122) Email: info@daviteq.com | www.daviteq.com...
- Page 9 USER GUIDE FOR ICONNECTOR 3G STHC-B-ISG02DB-03 STHC-B-ISG02DB-03-MN-EN-01 Jul-2020 This document is applied for the following products STHC-B HW Ver. FW Ver. Iconnector 3g Dualband, internal antenna, 1 x battery size D 3.6VDC and Item Code STHC-B-ISG02DB-03 external DC power, 1 x pulse input, 1 x 4-20mA input with 15v supply to external sensor, Ip67, 1 x M12-M for power, 1 x M12-F for IO 1.
- Page 10 GPRS Quadband/3G-Dual band/NB-IoT, internal antenna Host communication supports TCP/IP, UDP/IP, FTP, HTTPS, SNMP... Vietnam Type Approval QCVN 54:2011/BTTTT, QCVN 15:2015/BTTTT (DAVITEQ B00122019) Cerification Analog Input 1 x 4-20ma input with 15v supply to external sensor 1 x Pulse input with counting function, dry-contact, max 1Hz, auto-reset counter...
- Page 11 5. Operation principle 5.1 Process of measurement When the sensor sampling interval is reached, for example, 2 minutes (Battery Mode), iConnector will wake up and turn ON the power to supply power to the external sensor to start measuring. Depending on the type and characteristics of the external sensor, it may take a certain time to complete the measurement.
-
Page 12: Offline Configuration
8960 2300 float power supply External power supply voltage volt 8964 2304 float battery Battery voltage volt 8982 2316 byte gsm signal quality GSM signal strength uint32 I2C: sample_rate sensor reading cycle, e.g: 60 (sec) seconds. time of supplying power to the uint16 I2C: calc_time sensor before reading the I2C, (ms) - Page 13 Step 1: Open the cover of the iConnector Step 2:Connect the Configuration Cable to the UART Port in iConnector...
- Page 14 Step 3: Power the iConnector via M12 male connector on iConnector Step 4: Connect the USB port of the Configuration Cable to the Computer...
-
Page 15: Configuration Tool
5.3.2 Configuration tool You can download Configuration Tool with the following link: https://filerun.daviteq.com/wl/?id=s5QApxosVNZLbATxi0TtKVoJX4ms1PxD Unzip file and run file application "iconnector_config" Choose COM Port (the Port which is USB cable plugged in) Set the BaudRate: 9600, Parity: none Click “ Connect “ untill the Status displays “disconnected” to “connected“. It means the iConnector is being connected with computer;... - Page 16 Write in the Setting column the data to be configured into iConnector Click Sync to synchronize data into iConnector After synchronizing the data into iConnector, if the data displayed in the Value column shows the corresponding data, the configuration is completed. 5.4 SIM configuration iConnector 3G uses micro-SIM and needs to be configured to use the data network 1.
- Page 17 5.5 Configure sensor parameters on the iConnector 5.5.1 Configure I2C_Sensor tab We configure the parameters of 4-20mA sensor in I2C Sensor tab: I2C: sample_rate sensor reading cycle, e.g: 60 seconds. (sec) I2C: calc_time (ms) time of supplying power to the sensor before reading the I2C, e.g: 200 ms. The number of ADC samples taken in a reading of sensor data, the more samples the longer the sensor reading time.
- Page 18 I2C: prm1_b The b constants after calculation according to the formula Cut the upper threshold of I2C I2C: prm1_hi_cut e.g: If prm1_scaled_value > prm1_hi_cut then prm1_scaled_value = prm1_hi_cut Cut the lower threshold of I2C I2C: prm1_lo_cut e.g: If prm1_scaled_value < prm1_lo_cut then prm1_scaled_value = 0. I2C: sensor type Sensor type = 20 means that the I2C sensor reads 4-20mA I2C: error status...
- Page 19 6.2 IO Wiring & Sensor installation Install the sensor as shown below:...
- Page 20 Step 1: Open the back cover of the sensor Step 2:Wiring to sensors...
- Page 21 Step 3: Connect Sensor to Input 4 .. 20mA port of iConnector via M12 connector...
- Page 22 For more information about DP transmitter: https://filerun.daviteq.com/wl/?id=lT9lfZuEQUQksWLhFgSoQrs28sEGY0Kt 6.3 Power Supply & Battery installation 6.3.1 Power Supply of iConnector Connect 7 .. 48VDC power supply to iConnector via M12 Male connector Use M12 female connection cable to connect to iConnector...
-
Page 23: Battery Installation
6.3.2 Battery installation Steps for battery installation: Step 1: Using Flat Tip Screwdrivers to open the cover Step 2: Carefully pull out the top plastic housing... - Page 24 Step 3: Insert the type D battery 3.6VDC, please take note the poles of battery Step 4: Insert the top plastic housing and locking by Flat Tip Screwdrivers 7. Troubleshooting Phenomena Reason Solutions...
- Page 25 The value of the sensor is 0 Sensor connecting 4-20mA is Check sensor connection loose/not connected No power supply Check the power supply The network information of Check that the battery is empty or The iConnector does not the SIM card data is not installed correctly connected to the sever incorrect...
