Freedom Charge FDMC-1281 Installation Instructions Manual

2011 – Current Kia Optima Qi Wireless Charging Kit
Please read thoroughly before starting installation and check that kit contents are complete.
Items Included in the Kit:
Qi Wireless Charging Module with
Optima Specific Substrate
Power Harness with 3 amp Fuse
Optima Specific Non Slip Mat
Product guidelines sticker
These Instructions with Template
*Note this product is designed to work with Qi compatible devices. Please confirm that
your device is Qi compatible before installation. Visit
compatibility guide.
Safety Precautions:
Work in well ventilated area that is clear of obstructions.
Secure vehicle with tire chucks in both front and rear of tires.
Turn vehicle accessories OFF and ensure ignition key is in OFF position.
Wear safety goggles and snug fitting clothes.
Use tools only for their intended purpose and which are in good repair.
Only perform this task if confidence, skill, and physical ability permit.
NOTE: We strive to provide accurate and up-to-date installation instructions.
FDMC-1281 Optima .doc
(Kit # FDMC-1281)
Tools & Supplies Needed:
IMPORTANT: Do not place smart keys
within 15cm of charging mat. Vehicle
may not detect key to start vehicle. Do
not place metal objects in tray while
charging.
Page 1 of 3
Plastic Trim Removal Tool
Center Punch/Scribe Tool
Power Drill
1/2" Drill Bit or Uni bit
Wire Ties
Soldering Iron & Solder
Tape or Heat Shrink Electrical Tubing
www.brandmotion.com
(Recommended)
for phone
