2015 - Ford Mustang Qi Wireless Charging Kit
Please read thoroughly before starting installation and check that kit contents are complete.
Items Included in the Kit:
Qi Wireless Charging Module with
Mustang Specific Substrate
Power Harness with 3 amp Fuse
2015 Mustang Specific Non Slip Mat
These Instructions with Template
Removable Consumer Product Label
*Note this product is designed to work with Qi compatible devices. Please confirm that
your device is Qi compatible before installation. Visit
compatibility guide.
Safety Precautions:
• Work in well ventilated area that is clear of obstructions.
• Secure vehicle with tire chucks in both front and rear of tires.
• Turn vehicle accessories OFF and ensure ignition key is in OFF position.
• Wear safety goggles and snug fitting clothes.
• Use tools only for their intended purpose and which are in good repair.
• Only perform this task if confidence, skill, and physical ability permit.
NOTE: We strive to provide accurate and up-to-date installation instructions.
1222 Instructions 3-9-15.doc
(Kit # FDMC-1222)
Tools & Supplies Needed:
IMPORTANT: Do not place smart keys
within 15cm of charging mat. Vehicle
may not detect key to start vehicle. Do
not place metal objects in tray while
charging.
Page 1 of 5
INSTALLATION
I NSTRUCTIONS
Plastic Trim Removal Tool
10mm socket driver
7mm Socket Drive
Center Punch/Scribe Tool
Power Drill
1/2" Drill Bit
Wire Ties
Soldering Iron & Solder
Tape or Heat Shrink Electrical Tubing
www.brandmotion.com
(Recommended)
for phone
Advertisement
Related Manuals for Freedom Charge FDMC-1222
Summary of Contents for Freedom Charge FDMC-1222
- Page 1 INSTALLATION I NSTRUCTIONS 2015 - Ford Mustang Qi Wireless Charging Kit (Kit # FDMC-1222) Please read thoroughly before starting installation and check that kit contents are complete. Items Included in the Kit: Tools & Supplies Needed: Qi Wireless Charging Module with...
-
Page 2: Installation Instructions
INSTALLATION I NSTRUCTIONS Step 1: Use a plastic trim removal tool to remove Step 4: Remove (2) 7 mm sockets from under left and right side front console trim. rubber tray. Removal is not required but it does help with lifting the top of console. Step 5: Use a plastic trim removal tool to loosen Step 2: Remove (2) 7mm sockets from the front of the console top trim from inside the armrest. - Page 3 (2) 10mm nuts from the bottom studs. Step 9: On the power harness included with the Freedom Charge cut off the ringlet on the black wire (ground). Step 10: Splice the wires using military splice or soldering into the factory harness.
- Page 4 Lift up on the console to ensure there is clearance to drill the hole. Step 17: Connect the Freedom Charge plug to the power harness that was run to the armrest. Pull as Step 14: Run the power harness that was much excess power harness back into the connected to the power point into the ½...
- Page 5 Step 20: Test system. LED light will illuminate blue once accessories are on. Once Qi equipped device is placed on Freedom Charge LED will illuminate Green and charging begins. *Please note on some devices syncing may take up to 15 seconds.
