2014 – Current Silverado/Sierra Bench Seat Models
Qi Wireless Charging Kit (Kit # FDMC-1270)
Please read thoroughly before starting installation and check that kit contents are complete.
Items Included in the Kit:
Qi Wireless Charging Module with
Silverado/Sierra Specific Substrate and Mat
Power Harness with 3 amp Fuse
4 – Flat Head Torx 1/2" Screws
These Instructions with Template
Removable Consumer Product Label
*Note this product is designed to work with Qi compatible devices. Please confirm that
your device is Qi compatible before installation. Visit
compatibility guide.
Safety Precautions:
Work in well ventilated area that is clear of obstructions.
Secure vehicle with tire chucks in both front and rear of tires.
Turn vehicle accessories OFF and ensure ignition key is in OFF position.
Wear safety goggles and snug fitting clothes.
Use tools only for their intended purpose and which are in good repair.
Only perform this task if confidence, skill, and physical ability permit.
NOTE: We strive to provide accurate and up-to-date installation instructions.
For additional assistance please call Brandmotion Technical Assistance at (734) 619-1250 then dial 2.
1270 Instructions 9-15-14.doc
Tools & Supplies Needed:
IMPORTANT: Do not place smart keys
within 15cm of charging mat. Vehicle
may not detect key to start vehicle. Do
not place metal objects in tray while
charging.
Page 1 of 5
Plastic Trim Removal Tool
T-10 Torx Driver
Phillips Screw Driver
Center Punch/Scribe Tool
Power Drill
3/16" and 1/2" Drill Bits
Soldering Iron & Solder
Tape or Heat Shrink Electrical Tubing
www.brandmotion.com
(Recommended)
for phone
Advertisement
Related Manuals for Freedom Charge FDMC-1270
Summary of Contents for Freedom Charge FDMC-1270
- Page 1 2014 – Current Silverado/Sierra Bench Seat Models Qi Wireless Charging Kit (Kit # FDMC-1270) Please read thoroughly before starting installation and check that kit contents are complete. Items Included in the Kit: Tools & Supplies Needed: Qi Wireless Charging Module with...
- Page 2 Step 1: Using a Trim Removal Tool remove Step 4: Drill the (4) 3/16” holes. upper armrest cover. Step 5: Drill the (1) 1/2” holes. Step 2: Using a Phillips Screw Driver remove (4) screws to remove upper armrest tray. Step 6: Route connector of Charging Module through ½”...
- Page 3 Step 7: Align the (4) 3/16” holes with Step 10: Reassemble armrest tray with mounting holes on module and insert the (4) Charging Module in armrest lid and route 3/8” Pan Head T-20 Torx Screws through harness through ½” hole of lid. tray into module.
- Page 4 Step 13: Using Phillips Screw Driver remove screws in armrest bin. Step 16: Splice Red wire of Power Harness to the Red (12v ignition) wire of the keyed accessory power point plug and Splice Black wire of Power Harness to the Black (ground) wire of the power point plug RECOMMENDED: Solder wires and cover with Heat Shrink Tubing.
- Page 5 Step 21: Test system. LED light will illuminate Blue once accessories are on. Once Qi equipped device is placed on Freedom Charge LED will illuminate Green and charging begins. *Please note on some devices syncing may take up to 15 seconds. Coil locations vary on various devices;...
