Type A Machines 1 PRO Series Assembly page 3

Checking the Platform Home Position
The Platform Home is the position to which the
build platform moves when a print starts. If the
surface is too near, the filament will be blocked
from extruding and the extruder may make a
clicking sound. If the platform is too far, the
filament will not adhere to surface.
Adjusting the Platform Home Position
• Adjust the Platform Home position, by turning
the black knob a quarter turn at a time.
Clockwise lowers the platform, increasing
the distance between platform and extruder.
Counterclockwise raises it, decreasing the
distance between platform and extruder.
• Press the Platform Home button to move the
platform to the new setting after each
adjustment, then check if it is correct.
Preparing the Build Surface
• To help the print adhere, apply a single pass
of glue stick to the glass build surface.
IMPORTANT SURFACE TREATMENT NOTE
Some materials, such as PET, will bond
permanently with the glass build plate if
printed in direct contact. This will result in
damage not covered under warranty.
• Refer to the manufacturer of a material
for surface treatment requirements.
• Use a surface treatment whenever
using unfamililiar materials.
TYPE A MACHINES
TYPE A MACHINES
SERIES 1 & SERIES 1 PRO
Preparing to Print
Printing
Get more from your printer at the Type A Machines website.
Download Cura for Type A to prepare models for printing, get
©2016 Type A Machines, Inc.
Products in the manual may be covered by US and international
Patents. Type A Machines is a registered trademark of Type A
Machines, Inc. Any product names mentioned in this manual are
the property of their respective owners.
It's time to print. A model of a cone has been
included on the printer. This model is already
prepared, has optimized for print speed, and
should take a little over 15 minutes to print.
To print the Cone model:
• Clck the Files tab within the Series 1 interface
and locate the file named "Cone".
• Click the Printer icon to the right of the file and
the printer will begin to print.
The print head (and heated bed, if equipped) will
come up to temperature and the print will start.
Beware of hot components while in use.
You can monitor the print head and build platform
temperatures in the Temperature tab.
When finished, use the included spatula to
remove the print from the build platform. Avoid
putting pressure on the platform so that
alighment is not affected.
Congratulations
on your first print!
Get More from Series 1
the user manual, and shop for filaments and accessories.
http://www.typeamachines.com/gettingstarted
v2.7-1800 16-01-11
