3.

Parts and Functions

3.1.

Input/Output

1 1
1 MAIN POWER SWITCH
Switch the main power on/off.
2 AC IN
AC power input from the wall outlet.
3 HDMI OUT
HDMI video/audio output.
4 HDMI IN
HDMI video/audio intput.
5 AUDIO
Audio output
6 USB 3.0
Connect your USB storage device.
7 USB 2.0
Connect your USB storage device.
8 ETHERNET
Connect the ethernet.
9 Webcam
Connect the webcam. (Buy optional)
9
2
3 4
7
USB 3.0 USB 2.0
5V/0.9A 5V/0.5A
5 6 7
ETHERNET
8
