Magnetic flux
Depending on the application, the strength of the magnetic flux density on the individual
densities within areas of the welding torch can be controlled by regulating how deeply the welding torch is
the cleaning coil immersed in the cleaning coil.
for Robacta TC
2000 Twin, Ro-
NOTE!
bacta TC 2000
Twin US
When using the cleaning device, refer to the program sequence for details of the
welding torch immersion depth.
Cleaning coil
Diagram showing availa-
ble magnetic flux density
0 % 100 %
Immersion depth of
torch neck into clean-
ing coil
19 mm
14 mm
0.75 in.
0.55 in.
54 mm
2.13 in.
