Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts,
which may have come loose inside the carton during shipment. Identify and count all items and compare with
the PARTS LIST and/or HARDWARE LIST shown below.
Caution: Please read the instructions thoroughly before assembly.
1. We recommend that you assemble this product with the assistance of another person; this will make the
assembly easier, and will help eliminate damage to the product or injury to persons during assembly.
2. Please do not over tighten screws or bolts until the assembly is completed.
3. Please put all parts on a non-abrasive floor before assembly,and follow the assembly steps to assemble
your newly purchased product correctly and efficently.
PARTS LIST
NO.
COMPONENT
A
CHAIR BACK
B
SEAT FRAME
C
CUSHION SEAT
FRONT LEG
D
(LEFT)
FRONT LEG
D
(RIGHT)
SIDE
E
STRETCHER
(LEFT)
SIDE
E
STRETCHER
(RIGHT)
FRONT
F
STRETCHER
SKETCH
QTY.
2 PCS
2 PCS
2 PCS
2 PCS
2 PCS
2 PCS
2 PCS
2 PCS
MADE IN VIETNAM
ITEM NO. D1701-32S
GIA 30" COUNTER W/2 CHAIRS & SHELF
HARDWARE LIST
NO.
COMPONENT
FLAT WASHER
1
5/16" DIA.
SPRING
WASHER
2
5/16" DIA.
NUT
3
5/16" DIA.
ALLEN
4
WRENCH
5/16" DIA.
SHORT BOLT
5
1/4" x 1 3/4"
LONG BOLT
6
1/4" x 3"
WOOD SCREW
7
5/32" x 1 1/2"
SKETCH
QTY.
22 PCS
22 PCS
8 PCS
1 PC
6 PCS
8 PCS
24 PCS
PAGE: 1 OF 4
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for New Classic Home Furnishings GIA D1701-32S
Summary of Contents for New Classic Home Furnishings GIA D1701-32S
- Page 1 Assembly Instructions ITEM NO. D1701-32S GIA 30” COUNTER W/2 CHAIRS & SHELF Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come loose inside the carton during shipment. Identify and count all items and compare with the PARTS LIST and/or HARDWARE LIST shown below.
- Page 2 Assembly Instructions ITEM NO. D1701-32S GIA 30” COUNTER W/2 CHAIRS & SHELF To assemble the chairs, please follow the following steps and repeat for each chair: STEP 1 STEP 2 Lay the chair back on soft clean surface and install Insert side stretchers with wood screws.
- Page 3 Assembly Instructions ITEM NO. D1701-32S GIA 30” COUNTER W/2 CHAIRS & SHELF PARTS LIST HARDWARE LIST COMPONENT SKETCH QTY. COMPONENT SKETCH QTY. FLAT WASHER TABLE TOP 8 PCS 1 PC 5/16” DIA. SPRING WASHER BOX PANEL 1 PC 8 PCS 5/16”...
- Page 4 Assembly Instructions ITEM NO. D1701-32S GIA 30” COUNTER W/2 CHAIRS & SHELF To assemble the table, please follow the following steps: STEP 1 STEP 2 (Right) (Right) (Left) (Left) (Right) (Left) STEP 3 STEP 4 (Left) (Right) MADE IN VIETNAM PAGE: 4 OF 4...
