Bunk Bed Safety Warnings
1.
Follow the Information on the warnings appearing on the Upper bunk end structure
and on the carton. Do Not remove warning label from bed.
2.
Use only mattress which is 74"-75" long and 37 1/2"-38 1/2" wide on upper bunk.
Use only mattress which is 74"-75" long and 52 1/2"-53 1/2" wide on lower bunk.
3.
Ensure thickness of mattress does not exceed 8" and mattress is at least 5" below
upper edge of guardrails.
4.
Do not allow children under 6 years of age to use the upper bunk.
5.
Periodically check and ensure that the guardrail, ladder, and other components are
in their proper position, free from damage, and that all connectors are tight.
6.
Do not allow horseplay on or under the bed and prohibit jumping on the bed.
7.
Always use the ladder for entering and leaving the upper bunk.
8.
Replacement parts: replacement parts, including additional guardrails, may be
obtained from any of our New Classic dealer.
9.
Do not use substitute parts. Contact the manufacturer or dealer for replacement
parts.
10. Use of a night light may provide added safety precaution for a child using the
upper bunk.
11. Always use guardrails on both long sides of the upper bunk.
12. The use of water or sleep flotation mattress is prohibited.
13. Keep these instructions for future reference.
Max weight for upper bunk is 200 LBS.
STRANGULATION HAZARD-Never attach or hang items to any part of the bunk
bed that are not designed for use with the bed; for example, but not limited to,
hooks, belts and jump ropes.
MADE IN CHINA
Assembly Instructions
Canyon Ridge Twin-Full Bunk
New Classic Home Furnishings
TEL 909-484-7676 • FAX 909-484-2840 • WEB www.newclassicfurniture.com
1
Advertisement
Summary of Contents for New Classic Home Furnishings Canyon Ridge
- Page 1 Assembly Instructions Canyon Ridge Twin-Full Bunk Bunk Bed Safety Warnings Follow the Information on the warnings appearing on the Upper bunk end structure and on the carton. Do Not remove warning label from bed. Use only mattress which is 74”-75” long and 37 1/2”-38 1/2” wide on upper bunk.
-
Page 2: Parts List
Assembly Instructions Canyon Ridge Twin-Full Bunk Parts List Part # Description Part # Description Lower Headboard 39” Mattress Slat Set Upper Headboard Vertical Ladder Support. (Left+Right) Upper Headboard(No Guardrail Ladder Steps holes) Mattress Side Rails Storage Unit Ladder Side Rail Side Panel(Left+Right) 75”... - Page 3 Assembly Instructions Canyon Ridge Twin-Full Bunk Assembling Lower Bunk • Connect the headboard(1)and side panel(13) make sure the holes one the plate line up with the holes on the headboard, insert and tighten the Male-Female Bolts(D) . Insert 2 Barrel Nuts (E) into each end of the •...
- Page 4 Assembly Instructions Canyon Ridge Twin-Full Bunk Assembling Support Slats Layout the Mattress Support Slats (14) • with the webbing facing down. Anchor Slat behind cleat on Side Stat • Cleat Support provided at each corner. Screw in each end of the slats using the 1”...
- Page 5 Assembly Instructions Canyon Ridge Twin-Full Bunk Assembling Upper Bunk • Attach mattress side rail (4) and Ladder Side Rail (5) to the upper head board (2, 3) using the steps assembling Lower Bunk. • Attach 75”Guardrails (6) to the back portion of the upper bunk using the steps assembling Lower Bunk.
- Page 6 Assembly Instructions Canyon Ridge Twin-Full Bunk Assembling Support Slats Layout the Mattress Support Slats (9) with the • webbing facing down. Anchor Slat behind cleat on Side Stat Cleat • Support provided at each corner. Screw in each end of the slats using the 1” Wood •...
- Page 7 Assembly Instructions Canyon Ridge Twin-Full Bunk Assembling Ladder • Attach left ladder support (10) to steps (part 11) using Barrel Nuts (E)and 2 3/4” Rail Bolt(C). The top of the ladder supports have 2 predrilled holes for securing ladder hooks. Make sure to face those holes toward the top before assembling steps.
