INSTALLATION SHEET
GB
For installation: The minimum distance between the support surface of the recipients on the cooking device
and the lowest part of the hood must not be less than 43 cm in the case of electric cookers and 65 cm for gas or
combination cookers. If the installation instructions for the gas cooker specify a greater distance, this must be
taken into account.
To install, follow points (1 2 3 .....). Do not connect the appliance to the electrical power supply until
installation is completed.
WARNING: The exhaust pipe and clamps are not supplied and must be bought separately.
WARNING: Very heavy product; hood handling and installation must be carried out by at least two persons.
Note on installation and use: Read this manual before installing or using the hood. The Manufacturer declines
all liability for any faults, damage or fires caused by the appliance as a result of failure to observe the instructions
and recommendations given in this manual.
5019 318 33109
BG RO SL
HR GB
75
PL
CZ SK
H
Advertisement
Table of Contents
Related Manuals for Whirlpool AKR 953
Summary of Contents for Whirlpool AKR 953
- Page 1 INSTALLATION SHEET For installation: The minimum distance between the support surface of the recipients on the cooking device and the lowest part of the hood must not be less than 43 cm in the case of electric cookers and 65 cm for gas or combination cookers.
