Parts and Functions

AU242FHBHA
AU242FHBIA
AU282FHAIA
AU282FHAHA
AU342FHAIA
AU482FIAIA
AU482FIBIA
AU482FIBHA
AU522FIAIA
AU522FIAKA
AU48NFIAIA
AU48NFIBIA
AU48NFIBJA
AU52NFIAKA
AU55NFIAIA
AU60NFIAKA
Cautions:
Please cut off power supply of the outdoor unit when don't use the air conditioner for a long
time.
1
2
3
1
Air inlet
Air outlet
Air inlet
Service panel
4
Air inlet
Air outlet
Air inlet
Service panel
