WHAT'S IN THE BOX
• LED Fixture
• Small Pin Cross Machine Screws x 2 (AA)
• Wire Nuts x 3 (BB)
• Pointed Pin Cross Wood Screws x 4 (CC)
• Wall Anchors x 4 (DD)
WHAT YOU'LL NEED
• Screwdriver / Drill
• Wire Cutters
• Wiring supplies as specified by Electric Code
WARNING
•
Read all safety precautions and installation instructions carefully before
installing
•
Do not handle any energized fixture or attempt to energize any fixture with wet
hands or while standing on a wet or damp surface or in water
•
Ensure that the fixture is mounted onto a structurally sound surface that will
support the fixture
•
The fixture is designed for use in a 100-277VAC, 60Hz fused circuit. Do not use in
a dimming circuit
•
Do not install on a radiant-heating type ceiling
FAILING TO FOLLOW THESE INSTRUCTIONS MAY LEAD TO A POTENTIALLY FATAL
ELECTRICAL SHOCK OR PROPERTY DAMAGE
CW2 SERIES
COMMERCIALWRAPAROUND
INSTALLATION INSTRUCTIONS
For use with:
CW2-404-1
IMPORTANT
Before assembling your fixture,
please make sure that you carefully
read through this instruction sheet.
Ensure your fixture is installed by a
qualified licensed electrician.
Note: The important safeguards and
instructions that appear in this sheet
are not meant to cover all possible
conditions and situations that may
occur. It must be understood that
common sense, caution, and care
are factors that cannot be built into
any product. These factors must be
supplied by the person(s) caring for
and operating the fixture.
PREMISE LED Inc.
80-86 Carrier Drive
Toronto, ON Canada
M9W 5R1
PREMISELED.COM
1
