5MP ALL-IN-ONE DVR
Quick Start Guide
Note: Please read this instruction carefully for correct use of the product and preserve it for reference purposes.
All the examples and pictures used here are for reference only. There may be several technically incorrect places
or printing errors in this manual. The updates will be added into the new version of this manual. The contents of
this manual are subject to change without notice.This device should be operated only from the type of power
source indicatedon the marking label. The voltage of the power must be verified before using the same.

1. HDD Installation

This series of the product supports 1 SATA hard drive. Please make
sure that the device is powered off before the installation. The pictures
of the installation are only for reference, please take the real object as
the standard.
1. Loosen the screws to open the cover.
2. Screw the screws into the holes of HDD but
not tighten them.
3. Put the HDDs onto the bottom of the device.
4. Connect the power and data cables.
5. Turn over the machine and secure the HDD
6. Install back the cover and secure it with the
with the screws.
screws.
Tips: Please check the inside structure of the device and make sure the cables connected well
before installing the cover back.

2. Rear Panel Installation

4
3
2
1
4
3
2
1
ALARM IN
CVBS
VIDEO IN
AUDIO
4
3
1
2
AUDIO IN
OUT
ALARM OUT
VGA
Rare Panel for AVR-TS504A
AUDIO
IN
8
6
4
2
AUDIO
7
5
3
1
CVBS
VIDEO IN
OUT
VGA
Rare Panel for AVR-TS508A
3. Startup & Shutdown
• Startup
1. Connect the monitor and the power.
2. The device will boot and the power indicator will display blue.
3. A wizard window will pop up.
• Shutdown
Click "Start" and then select "Shutdown" icon. This will bring up a
shutdown window. The device will shut down by clicking "OK" button.
Then disconnect the power.

4. Login

The default username is admin and the default password is 123456.
You must configure the wizard if you start the DVR for the first time
and you may change the password when you configure the wizard for
the first time. You can skip the settings of wizard next time. Click
"Start" and select "Login". This will take you to see a login box. Input
default username and password you set and you can see the live
image.
Login
Username
admin
Enter Password
Password
Display Password
Log In Automatically
Edit Security Question
Login
5.
Analog Camera Connection
First connect the camera to the DVR. Then go to Start →Settings →
Camera→Manage Camera→Camera Signal to set the signal mode of
the camera. The actual signals input shall correspond to the video
mode. Please refer to User Manual for details.
6. Network Configuration & Add IP Camera
After you finish adding IP cameras, you can see the live images through
the monitor of the DVR. The following will mainly introduce how to
B
A
add the IP cameras via LAN/WAN.
LAN
USB
DC12V
RS
485
• LAN
1. Set the network of the DVR. Go to Start → Settings →
Network → TCP/IP. Input IP address, subnet mask, gateway, etc.
If using DHCP, please enable DHCP in both the DVR and router.
2. Go to Start → Settings → Network → Port. Input HTTP port
B
A
(the default value is 80), server port (the default port is 6036).
LAN
USB
DC12V
RS485
3. User may change the MTU (Maximum Transmission Unit) value
according to the real network situation.
Internet
Click "Apply" to save the settings.
IP Address Settings
Ethernet Port 1 ( Online )
Obtain an IPv4 address automatically
Address
Subnet Mask
Gateway
MTU
Obatin DNS server address automatically
Preferred DNS
Alternate DNS
4. Go to Start → Settings → Camera → Add Camera. The DVR
will automatically refresh the cameras searched. The IPC which
supports the Onvif protocol may be added manually. If the IPC
searched is not in the same local network as the DVR, you
should select the device and click
Quickly Add
Manually Add
No.
Address
1
192.168.1.20
2
192.168.1.38
3
192.168.2.45
Selected: 1/3
Remain Bandwidth: 108 / 120 Mb
Cancel
Obtain an IPv6 address automatically
192 . 168 .
1 .
2
Address
192 . 168 .
1 .
2
0
.
0
.
0 .
0
Mask Length
0
192 . 168 .
1 .
1
Gateway
192 . 168 .
1 .
1
1500
192 . 168 .
1 .
1
0
.
0
.
0 .
0
to modify the IP address.
Add Camera
Add Recorder
Port
Edit
Subnet Mask
Protocol
Model
Version
80
255.255.255.0
XXX
XXX
3.4.2
80
255.255.255.0
XXX
XXX
3.4.2
80
255.255.255.0
XXX
XXX
4.0.0.1.beta1
Default Password
Add
Cancel
Edit Camera
Mac Address
CE :98 :23 :75 :35 :22
Address
192 .168 . 1 . 45
Sync to IPC
Subnet Mask
255 . 255 . 255 . 0
192 .168 . 1 . 1
Gateway
Username
admin
Password
OK
Cancel
