ViewSonic PRO8450W Specification Sheet page 2

Pro8450w
NETWORKABLE HIGH BRIGHTNESS WXGA PROJECTOR – 120HZ AND 3D-READY
Optional Accessories
> Replacement Lamp
> Universal Ceiling Mount Kit
> Wireless G Presentation Gateway
> USB Wireless Adapter
®
> Extended Express Exchange
Projection 16:10 Aspect
Distance Wide
M Feet M Inches
1.5 4.92 1.21 47.5
1.8 5.90 1.45 57.0
2 6.56 1.61 63.3
3 9.84 2.42 95.1
5 16.40 4.02 158.4
10 32.80 8.05 316.8
ViewSonic Corporation's QMS & EMS have been registered
to ISO 9001 & ISO 14001, respectively, by TUV NORD.
Sales: (888) 881-8781 . SalesInfo@ViewSonic.com . ViewSonic.com
*Running eco-mode exclusively can extend lamp life. See ViewSonic.com for full Express Exchange details. Specifications and availability are subject to change
without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete details. Corporate names, trademarks
stated herein are the property of their respective companies. Copyright © 2010 ViewSonic Corporation. All rights reserved [15867-00B-10/11] Pro8450w-1
For more product information, visit us on the web at ViewSonic.com
DISPLAY
INPUT SIGNAL
COMPATIBILITY
CONNECTOR
AUDIO
POWER
CONTROLS
RLC-059
WMK-005
WPG-360
WPD-100
PRJ-EE-08-03
Tele
M Inches
0.8 31.5
0.96 37.8
1.07 42.0
1.60 63.1
2.67 105.1 OPERATING
5.34 210.2 CONDITIONS
NOISE LEVEL
DIMENSIONS
(W x H x D)
WEIGHT
REGULATIONS
PACKAGE CONTENTS
WARRANTY
Type 0.65" Digital Micromirror Device (DLP
Resolution WXGA 1280x800 (native)
Lens 1.5× Manual optical zoom / Manual optical focus
Keystone Vertical digital keystone correction: +/– 40 degrees
Size 30"–300" / 0.76m–7.6m
Throw Distance 0.9m–10m / 3ft–32.8ft
Throw Ratio 1.46–2.2:1
Lamp 280 watt
Lamp Life (Normal / Eco-mode) 4000 / 5000* hours
Brightness 4500 Lumens
Contrast Ratio 4300:1 (dynamic)
Aspect Ratio 16:10 (native), 16:9, 4:3, Auto
Color Gamut 70% NTSC 1931 CIE
Computer and Video NTSC M (3.58 MHz), 4.43MHz, PAL (B, D, G, H, I, M, N, 60),
SECAM (B, D, G, K, K1, L), SD 480i and 576i, ED 480p and
576p, HD 720p, 1080i and 1080p
Frequency Fh: 31–100KHz, Fv: 48–120Hz
PC VGA to UXGA
Mac Up to UXGA (scaled)
®
RGB Input 15-pin mini D-sub (x2)
RGB Output 15-pin mini D-sub
Digital Input HDMI 1.3
Component RCA (x3)
Composite Input RCA jack
S-video Input 4-pin mini-DIN
Audio Input 3.5mm mini jack (x2), RCA (L/R) x1
Audio Output 3.5mm mini jack
Mic Input 3.5mm mini jack
Screen Trigger 3.5mm (12V/1A)
Control RS-232 (DB-9)
Network RJ-45
USB Type A: for PC-less slide show presentation - support JPEG,
BMP, TIFF, PNG, GIF from USB flash drive, optional wireless
USB adapter
Mini-B: for direct presentation from PC (not Mac compatible)
Speaker 10W (x2)
Voltage 100~240VAC (Auto Switching), 50/60Hz (universal)
Consumption 350W (typ) / <1W (stand-by mode)
Basic Power, keystone/arrow keys, left/blank, menu/exit,
right/panel key lock, enter, source
OSD Picture: Brightness, Contrast, Color Setting, User Color,
Auto Keystone, Keystone, Aspect Ratio, Image, White
Intensity, Gamma, 3D Sync, 3D Sync Invert
Video/Audio: Frequency, Tracking, H Position, V Position,
Overscan, Noise Reduction, Video Setting, Audio Setting,
Microphone Volume, Speaker Volume, Mute
Setting: Manual Position, Projection, Signal Type, Power
Saving, Auto Source, Eco-mode, Filter Mode, High Altitude,
OSD Timeout, OSD Transparency, Presentation Timer
Information: Input Source, Resolution, H Frequency, V
Frequency, MAC Address, Filter Hours, Filter Hours Reset,
Lamp Hours, Lamp Hours Reset, Factory Default
Option: Blank Screen, Password, Start up Screen, Close
Captions, Green Mode, DC 12V, Others, Function, Test
Pattern, Quick Power ON, Quick Cooling
Network: Wired LAN, Wireless LAN, Network Restart
Temperature 32ºF–104ºF (0ºC–40ºC)
Humidity 10%–90% (non-condensing)
Altitude 0~6,000 ft (1,800m), operational up to 10,000 ft (3048m)
Normal / Eco-mode 32dB / 27dB
Physical 13.1 x 4.3 x 10.4 (in) / 333 × 110 × 263 (mm)
Packaging 16.3 × 14.8 × 7.5 (in) / 415 × 377× 190 (mm)
Net 8.5 lb. (3.86 kg)
Gross 11.8 lb. (5.36 kg)
CB, RoHS, SVHC, WEEE, UL/cUL, FCC-B, ICES-004, TUV-S
(Argentina), NOM, PSB, C-tick, KC, CE, GOST-R, Hygienic,
UKrSEPRO, CCC
ViewSonic projector, power cable, VGA cable,
remote control/laser with batteries, lens cap, soft carrying
case, Quick Start Guide, ViewSonic Wizard DVD (with User Guide)
3-year limited warranty on parts, 1-year limited warranty
on lamp, 1st year Express Exchange
™ )
® service.
