SIRS Navigation KCA0101C Component Maintenance Manual With Illustrated Parts List page 32

C. Stem Assembly (80) and Compass Card (130)
CAUTION:
NOTE: When you do this procedure, hold the 'stem bracket', the assembly will
move when the screws are removed. Movement of the 'stem bracket'
can damage the card assembly.
(1) Hold the stem assembly (80) and remove the two screws (90).
(2) Remove the stem assembly and compass card (130) from the compass
bowl.
(3) Remove the compass card from the stem assembly and put the stem
assembly in a clean container.
D. Lamp Housing Assembly (230)
(1) Remove the cap (250) and the lamp (240).
(2) Remove the lamp housing assembly (230) from the 'compass bowl
assembly'.
E. Lead and Socket Assembly (260)
NOTE: This item does not sub-divide into separate components. The
PAGE 3002
34-25-21
APR 10/03
The document reference is online, please check the correspondence between the online documentation and the printed version.
SIRS NAVIGATION LTD
COMPONENT MAINTENANCE MANUAL
THE STEM ASSEMBLY AND COMPASS CARD ASSEMBLY
ARE DELICATE ITEMS. BE CAREFUL NOT TO CAUSE
DAMAGE.
item is not always supplied with the compass when it is sent for
repair.
