The compass must be installed with two 'non-magnetic' screws, with a head
diameter of dimension 6.5mm to 6.9mm.
CAUTION:
NOTE: Refer to the installation drawing for detailed information.The compass
E. Leading Particulars
The leading particulars for each compass are shown in table 1 below
KCA0101W
KCA0104W
KCA0104FY
KCA0105W
KCA0106W
KCA0112W
KCA0113W
KCA0113FY
KCA0114W
WL1001KCA1
The document reference is online, please check the correspondence between the online documentation and the printed version.
SIRS NAVIGATION LTD
COMPONENT MAINTENANCE MANUAL
THE SCREWS THAT ATTACH THE COMPASS MUST NOT
BE OVER-TIGHTENED.
does not need electrical power to operate, other than for illumination. The
compass will operate after installation and 'magnetic correction'.
Magnetic correction is required to correct for magnetic errors caused by
the aircraft, local components or instruments. A correction procedure for
the compass is specified in page Block 11001 Special Procedures.
Standby Compass - Leading Particulars
None
None
330Ω
330Ω
330Ω
330Ω
820Ω
390Ω
390Ω
47Ω
5v
None
Table 1
White
White
Fluorescent Yellow
White
Grey
White
White
White
Fluorescent Yellow
White
White
PAGE 3
34-25-21
APR 10/03
