Maintenance
The equipment shown in the dashed box is required for 1X
Amplitude and Phase, 2X Amplitude and Phase, Not 1X
Amplitude, and S
Keyphasor®
Signal
Multimeter
Input Signal
The Test Equipment outputs should be floating relative to earth ground.
.
98
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Amplitude.
max
Keyphasor Multiplier/Divider
Keyphasor®
I/O Module
100 µF
40 kΩ
Function Generator
Proximitor®
Seismic I/O
Module
Radial Vibration Test Setup
3500/42 Operation and Maintenance
-18
Vdc
Power Supply
