- Page 1 FLAME PANMIX - Dual Panning Recorder MANUAL Version 1.00...
- Page 2 MANUAL FLAME PANMIX Version 1.00 Contents 1. Short description ..............3 2. Hardware / Connections ............. 3 2.1 Connection to the modular system (Doepfer bus) 2.2 Module overview 2.3 Module backside 3. Handling ................3.1 Manual mix mode (Stop) 3.2 Record 3.3 Play back...
- Page 3 LFO. In addition, there are three other audio / CV signal inputs (one mono and stereo left + right), which are routed directly to the output and mixed together with the two PAN channels. So you can directly mix other sources and e.g. connect two or more "PANMIX" modules together.
- Page 4 2.2 Modul overview Key RECORD Mode LED Key PLAY Key STOP Panning Mix pot RESET input (0/5v) Channel Audio/Signal input (+/-5v) CV Panning input (+/-5v) Audio/Signal direct inputs (+/-5v) Audio/Signal stereo output (+/-5v)
- Page 5 Insert the backup battery before connecting the unit to your modular rack The PANMIX module uses a standard 3v lithium backup battery, type CR2032. Insert the provided battery or a comparable battery into the battery compartment as shown below. The battery is needed to keep recordings and settings stored when the Eurorack case is turned off.
- Page 6 3. Handling 3.1 Manual mix mode (Stop) After switching on, the module is in STOP mode. All LEDs are off. With the respective panning potentiometer of the track you can now control the applied signal of the channel between left and right of the stereo output.
- Page 7 In addition, there are three other audio / CV signal inputs (one mono and left + right) routed directly to the output and mixed together with the two PAN channels. So you can directly mix other sources (only with modular level) and e.g. connect two or more "PANMIX" modules together.
- Page 8 - electric damage caused by improper connecting (wrong power supply/ jacks/ MIDI connections/ voltage problems). If you have any complaints please contact your dealer or send an e-mail to: service@flame-instruments.de 4.3 Terms of production conformity: CE, RoHS, UL 4.4 Disposal The device is produced with RoHS-conformity (subject to the regulations of the European Union) and is free of hazardous substances (like mercury, plumb, cadmium and hexavalent chrome).
