Components:
1
90000104
2
90001100
2
90000929
2
90001092
Hardware Kit: 99010042
2
99122001
4
99433002
2
99123001
4
99371004
4
99372002
8
99373003
350 S. St. Charles St. Jasper, In. 47546
Ph. 812.482.2932 Fax 812.634.6632
65-70 Impala Front MuscleBar
Sway bar
Bushing and strap kit
12mm end link
Tube of Lithium grease
12mm x 1.75 Lock nut
7/16" SAE flat washer
12mm lock washer
3/8" x 1 ¼" USS bolt
3/8" USS Nylok nut
3/8" SAE flat washer
www.ridetech.com
Part # 11289100
PosiLink to lower arm
PosiLink to lower arm
PosiLink to sway bar
Frame bracket
Frame bracket
Frame bracket
Advertisement
Table of Contents
Related Manuals for Ridetech MuscleBar 11289100
Summary of Contents for Ridetech MuscleBar 11289100
- Page 1 350 S. St. Charles St. Jasper, In. 47546 Ph. 812.482.2932 Fax 812.634.6632 www.ridetech.com Part # 11289100 65-70 Impala Front MuscleBar Components: 90000104 Sway bar 90001100 Bushing and strap kit 90000929 12mm end link 90001092 Tube of Lithium grease Hardware Kit: 99010042 99122001 12mm x 1.75 Lock nut...
- Page 2 11289100 Installation Instructions *****This sway bar is designed for use with our front StrongArms***** 1. Slide the sway bar though the same holes in the frame that the factory bar went through. 2. Install the new polyurethane bushing over the sway bar. Lubricate with the Lithium grease supplied.
- Page 3 7. Install the lower StrongArms. 8. Screw one end of the PosiLink into the end of the sway bar. A 12mm lock washer will be used between the stud and the sway bar. 9. The other end of the PosiLink will attach to the tab on the StrongArm using a 12mm flat washer and locking nut.
