  • Page 1 CORE HEALTH & FITNESS 8RDE REAR DRIVE ELLIPTICAL OWNER'S MANUAL...

  • Page 2: Table Of Contents

    REQUIRED TOOLS PROCEDURE ..............7 FIRST TIME SETUP ..............11 OPERATION LED CONSOLES ........................12 MAINTENANCE MODE ..............14 MAINTENANCE ........................18 REPLACEMENT PARTS ........................19 9-6180-XXXXP0 - 8RDE ..............19 700-0549-XX - DISPLAY, LED, BCS ............23 SUPPORT & SERVICE ........................24 Page 2...

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS WARNING! Before using this product, it is essential to read the ENTIRE Owner’s Manual and ALL installation instructions. The Owner’s Manual describes equipment operation and instructs members on how to use correctly and safely. Read all warnings posted on the machine. Health related injuries may result from incorrect or excessive use of exercise equipment.
  • Page 4 To ensure the proper use of the equipment in a • 8RDE - 350 lbs. / 159 kg. safe manner, all users of the equipment should read this manual before using the machine. This 3.

  • Page 5: Important Label Locations

    If you find any stickers missing or damaged the replacement numbers are shown on the support site and following pages. See Support and Service to order replacements. Note: Sticker/Label images are not to scale. PRODUCT SPECIFICATIONS SKU: 9-6180-XXXXP0 Desc: 8RDE 050-5929 Max User CONSOLE WARNING Unit Weight...

  • Page 6: Assembly

    19mm Open-Ended Wrench • 7/16” Crowfoot Socket Parts Included In the Box: Description 620-9133 OWNERS MANUAL, 8-RDE, 9-6180-XXXXP0 721-1661 KIT, HARDWARE, 8RDE 721-1586-XX ASSY. BASE, RD-CT, BLK 050-5481 ASSY, PACKAGING, BOX, RD-CT 721-1577-XX SHROUD, PIVOT, FRONT, LEFT, 8-RDE 721-1576-XX SHROUD, PIVOT, REAR, LEFT, 8-RDE...

  • Page 7: Procedure

    PROCEDURE 1. Adjust the four Leveling Feet (140-3613) so the machine is stable, then remove the feet and tighten the lock nuts on the feet using a 19mm open-ended 140-3616 wrench. Once the lock nuts are tight, reinstall the feet. (See Fig.
  • Page 8 7. Use a torque wrench with a 7/16” crowfoot socket to secure the Left Upper Swing Arm (721-1616) to the Left Lower Swing Arm (721-1597-XX) using four Washers (120-0410), four Lock Washers (120-3409), and four Hex Head Cap Screws (110-3727). 110-3727 TORQUE TO 11 Ft-Lbs (15 Nm).
  • Page 9 721-1625-XX 721-1574-XX 110-3573 11. Use a #2 phillips screwdriver to secure the 721-1575-XX Front Neck Shroud (721-1575-XX) and Rear Neck Shroud (721-1574-XX) to the Neck (721-1625-XX) and frame using five screws (110-3573). Fig. 8 110-4449 020-4447 12. Use a 3mm allen key to install the two cupholders (020-4447) onto the mast and secure with four Socket Head Cap Screws (110-4448) and four Nylon Nuts (110-4449).
  • Page 10 15. Drape all wires from the base out the back of the mast weldment prior to installing the console. 16. Use a torque wrench with a 10mm socket to secure console to frame weldment with four screws 110-4447 as shown in Fig. 12. TORQUE TO 7.4-11 Ft-Lbs (10-15 Nm) If installing a PVS kit or 800/900 MHz controller, please refer to the...

  • Page 11: First Time Setup

    “model” is shown, then press the enter key to select the model sub menu. 5. Use the Level keys to choose “8RDE”, then press enter to save the selection. Fig. 14 CONNECT WIFI Option 1 (Recommended): Alter facility SSID to match information built into LED display.

  • Page 12: Operation Led Consoles

    Self-Powered Product: Star Trac Electronic Bikes and Ellipticals as well as StairMaster FreeClimbers with LED console are often used in facilities in a self-powered state. This wireless charging tray is designed to charge mobile phones on these self-powered products. Some limitations may apply.

  • Page 13: Display Measurements

    Display Measurements Message Window The top display window includes several measures: Current total workout time TIME Total distance traveled in mile or DISTANCE Current HR in beats per minute, HEART RATE if available Current total calories CALORIES Progress Window & Track Shows a graphic representation of elevation during a program.

  • Page 14: Maintenance Mode

    MAINTENANCE MODE Maintenance Mode allows access to service and diagnostic information, as well as provides the ability to adjust certain program default parameters. To enter Maintenance Mode: 1. Press and hold the 1, 2 on the left keypad and the 8 key on the right keypad together. 2.

  • Page 15: Manually Updating Firmware

    A complete list of the items that you may display and change in Maintenance Mode: Highest Highest Item Lowest Value Default Notes Item Lowest Value Default Notes Value Value SYSTEM CALIBRATION DISP V0.3.1 (1) SPD CAL 00.09 (02) ELV CAL Elevation calibration function V2.3.5 EXIT...

  • Page 16: Fcc Warning

    FCC INFORMATION & INDUSTRY CANADA WARNING FCC Warning This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. CAUTION: Text Changes or modifi cations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

  • Page 17: Ic Radiation Exposure Statement

    (ii) for devices with detachable antenna(s), the maximum antenna gain permitted for devices in the bands 5250- 5350 MHz and 5470-5725 MHz shall be such that the equipment still complies with the e.i.r.p. limit; pour les dispositifs munis d’antennes amovibles, le gain maximal d’antenne permis pour les dispositifs utilisant les bandes de 5 250 à...

  • Page 18: Maintenance

    MAINTENANCE TOOLS Working on this product will require basic and/or sometimes specialty tools based on the type of service that will be performed at any time. To assist, we recommend having the tools listed available when performing maintenance. • Metric Allen Key Set •...

  • Page 19: Replacement Parts

    SHROUD, NECK, REAR, 8-RDE 050-2215 LABEL, GENERAL WARNING, 8 BCVS FC 721-1575-XX SHROUD, NECK, FRONT, 8-RDE 050-6022 190mm, EXTRUDE DECAL, STAR TRAC 721-1576-XX SHROUD, PIVOT, REAR, LEFT, 8-RDE 050-6046 LABEL, CURVED BASE PLATE, VLAD, 8-RDE 721-1577-XX SHROUD, PIVOT, FRONT, LEFT, 8-RDE...
  • Page 20 721-1350 130-1705 731-0367 718-1127 731-1045 721-1372 718-5067 740-4552 110-3722 110-3026 721-1339 721-1045 740-7142 110-3510 120-0495 120-0490 731-5519 Fig. 20 Battery and Lower Control Board Fig. 21 Fly Wheel 717-0079 721-1392 110-3026 050-6046 711-3397-XX 130-1694 110-1823 140-3616 721-1581-XX 721-1580-XX 721-1583-XX 721-1582-XX 110-3573 Fig.
  • Page 21 731-1071 721-1597-XX 721-1619 720-5319 110-1833 050-2142 110-4480 721-1612 721-1595-XX 120-3030 720-5318 110-3726 110-4210 170-0729 721-1621 721-1623 Fig. 24 HR Grips and Cupholders Fig. 25 Lower Swing Arms 721-1302 110-4072 110-3671 721-1304-XX 721-1303-XX 721-1619 731-0411 050-2215 721-1301 721-1625-XX 740-4588 721-1336 120-0460 721-1574-XX 740-7825 110-3479...
  • Page 22 110-1833 050-2142 110-3726 120-3030 721-1606-XX 721-1595-XX 050-6022 721-1346 120-0460 110-4475 721-1608 740-8145 721-1630-XX 110-3723 721-1416 721-1607-XX 721-1634-XX 120-0490 110-3510 120-0495 110-3573 Fig. 28 Rear Shrouds Fig. 29 Swing Legs 260-0987 721-1615 740-7898 721-1616 731-0373 721-1579-XX 721-1578-XX 731-1363 110-3727 120-0410 721-1577-XX 721-1576-XX 740-9300 717-0380 140-3418 731-0363 110-3573...

  • Page 23: 700-0549-Xx - Display, Led, Bcs

    721-1407 721-1408 220-0384 130-1807 220-0387 050-5482 721-1658 721-1430 170-0739 721-1661 220-0385 Fig. 32 Wiring 700-0549-XX - DISPLAY, LED, BCS Part Number Qty Description Part Number Qty Description 050-5929 START STOP, LED DISPLAYS 701-0561 CABLE, GEM, LED CONSOLE 050-5937 KEYPAD, NAV BAR, LED DISPLAYS 701-0562 CABLE, USB A AND C, CARDIO CONSOLE 050-5951...

  • Page 24: Support & Service

    SUPPORT & SERVICE CORE CONNECT Core Connect is your portal to all things service! Whether you need to order parts or register your warranty, Core Connect is the most effective way to get what you need fast and keep your facility operating smoothly. OFFERS 24-HOUR SELF SERVICE ACCESS TO: •...
