Cellinx CamPilot STH900 User Manual

Full hd 1ch. network video transmitter
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

C amP il o t S T H90 0
Full HD 1ch. Network Video Transmitter
User Manual
Before installing and using the product,
please read this manual carefully.
Be sure to keep it handy for later reference.
The adaptor and LAN cable are sold separately.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CamPilot STH900 and is the answer not in the manual?

Questions and answers

Related Manuals for Cellinx CamPilot STH900

Summary of Contents for Cellinx CamPilot STH900

  • Page 1 C amP il o t S T H90 0 Full HD 1ch. Network Video Transmitter User Manual Before installing and using the product, please read this manual carefully. Be sure to keep it handy for later reference. The adaptor and LAN cable are sold separately.
  • Page 2 ■ Mounting Surface The mounting surface material must be strong enough to support the product. ■ CamPilot STH900 can be used for surveillance purpose. Be thoroughly informed of related regulations prior to installation to ensure compliance with such regulations.
  • Page 3 Overview Features and Appearance CamPilot STH900 is a Network Video Transmitter that transmits real-time high- resolution digital video and audio data with H.264 high compression rate over Internet or Intranet. 1. USB : Reserved 2. RS232 < 8 Pin connector>...

  • Page 4: Specification

    TCP, IP, HTTP, DHCP, FTP, DNS, DDNS, NTP, ICMP, Protocol SMTPE, UPnP, RTP, RTSP, Onvif Web Browser IE 8.0 or above Software Cellinx SDK 4.0 Security MD5 Password / iptables (firewall) Operating Temperature 0°C ~ 40°C / 32°F ~ 104°F Power Requirement DC 12V / 1.0A...

  • Page 5: Basic Connection

    (8) LINE OUT : Line Level ouput (Ø 3.5 stereo jack, 8Ω) (9) Video Output : for maintenance (BNC jack) Device control (ex. Electronic) PTZ control by RS422 (485) display) Front ◀ CamPilot STH900 PTZ camera (HD-SDI output) Rear ◀ Power Mic. Speaker Video Output: for maintenance Amplified Mic.

  • Page 6: Connection Example

    Connection Connection Example Camera (HD-SDI output) PTZ Camera (HD-SDI output) CamPilot STH900 CamPilot STH900 Local Network Public Network LAN Cable 인터넷 또는 인트라넷 Router Monitoring PC Monitoring PC Connection Example Monitoring PC Requirements Item Specification Processor Pentium Core2 Duo or more...

  • Page 7: Setting An Ip Address

    Network Setting an IP address Change the network setting value with the program “NVTManagement” 1. NVTManagement execution • Execute the file “NVTManagement.exe” 2. IP address set-up • Click the button “NVT Scan”, select the model. • Input the IP address, Subnet Mask, Gateway and DNS Server IP address, click the button “Apply”...
  • Page 8 Network 3. Accessing to CamPilot STH900 with a web browser Open a web browser on a monitoring PC and enter the IP address assigned to a CamPilot STH900 as following Example> http://192.168.1.2 • The page as below shows up after the connection is completed.
